| System functionality | 5 |
Monitoring patient effort
Administered breaths triggered by patient
effort are highlighted in the waveform display
area:
01-01 13 00
A purple color is superimposed on the
inspiratory phase of either the pressure curve
(pressure triggering) or the flow curve (flow
triggering). In addition, "Triggering" appears
in the upper left part of the waveform display
area.
FLOW-i 4.2, User's Manual 103
