Gas analyzer
Desflurane
Drift of measurement accuracy
• The respiration rate limit for accurately measured end-tidal values is < 60 breaths/minute for I:E =
1:1, < 40 breaths/minute for I:E = 1:2 and < 30 breaths/minute for I:E = 1:3.
• The accuracy of the gas measurements may be affected if the Ethanol concentration is higher than
0.1%, the Methane concentration is higher than 1% or the Acetone concentration is higher than 1%.
• The partial pressure and the percentage volume of CO
the amount of water vapor in the breathing gas. A partial H
automatically compensated for by the analyzer. Higher H
gas sample; at 30 cmH
Inspiratory and End-Tidal O
Concentration
Inspiratory and End-Tidal CO
Concentration
Inspiratory and End-Tidal N
Concentration
Inspiratory and End-Tidal Agent
Concentration
Gas measurement typical response times 10-90%
O
2
N O
2
CO
2
AA
Gas measurement typical response times 0-90%
O
2
N O
2
CO
2
AA
Primary anesthetic agent identification
A primary anesthetic agent will be identified by the gas analyzer if the concentration is higher than 0.4%
(ISO accuracy) or 0.15% (Full accuracy)
FLOW-i 4.2, User's Manual
Gas conc.
0 - 1%
1 - 5%
5 - 10%
10 - 15%
15 - 18%
> 18%
The accuracy includes stability and effects of device drift during
operation between calibrations.
O the general error of all measured gases is -2%.
2
YES
2
YES
2
O YES
2
YES
500 ms at a sampling rate of 225 ml/min
250 ms at a sampling rate of 225 ml/min
250 ms at a sampling rate of 225 ml/min
300 ms at a sampling rate of 225 ml/min
3800 ms at a sampling rate of 225 ml/min
3600 ms at a sampling rate of 225 ml/min
3600 ms at a sampling rate of 225 ml/min
3700 ms at a sampling rate of 225 ml/min
| Technical specifications
Accuracy [% ]:
ABS
± 0.15
± 0.2
± 0.4
± 0.6
± 1.0
Unspecified
, N O, O and anesthetic agent depend on
2 2 2
O pressure of up to 11 cmH
2
O partial pressures will further dilute the
2
Interference [% ]
ABS
CO 0
2
N O 0.1
2
O 0.1
2
2nd agent 0.2
O is
2
