- Page 1 GETINGE DRYING CABINET S-363 USER MANUAL 6001300802...
- Page 2 GETINGE’s written consent. The content may not be reused by third parties or used for unauthorized purposes. Violators will be prosecuted. Additional copies of this manual can be obtained from GETINGE for a fee. © Copyright 2013 GETINGE, Reprinting prohibited.
-
Page 3: Table Of Contents
7 ERROR CODE 1......................15 7.1 Drying anaesthetic and respiratory hoses and bellows........15 7.2 Maintenance when necessary................15 7.3 Cleaning the filter cassette................16 7.4 Overheating cut-out................... 17 8 ADDRESSES......................18 Alphabetical index......................21 USER MANUAL GETINGE DRYING CABINET S-363 3 (24) - Page 4 4 (24) USER MANUAL GETINGE DRYING CABINET S-363...
-
Page 5: Introduction
GETINGE DISINFECTION AB Ljungadalsgatan 11 PO Box 1505 SE-351 15 Växjö, Sweden 1.2.4 Warranty The product warranty applies in accordance with the agreement reached between the Getinge sales company and the customer. USER MANUAL GETINGE DRYING CABINET S-363 5 (24) -
Page 6: Safety Instructions
(100 kg) and high center of gravity. 2.2 Isolator switch The drying cabinet should be provided with a separate main switch in the power supply line, easily accessible on the wall. See section 5 ELECTRICAL INSTALLATION. 6 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 7: Warning Symbols
This symbol indicates a warning in the text concerning high voltage (>2000 V). It gives warning of dangers which could lead to minor or major injury to the person and even to a fatality. USER MANUAL GETINGE DRYING CABINET S-363 7 (24) -
Page 8: Technical Data
415 V, 3N+PE, 50/60 Hz 7.8 A 3.7 kW C10 A Pollution degree Max altitude 2000 m Indoor use only Overvoltage category Main supply voltage +- 10% at nominal voltage short fluctuations term. 8 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 9: Drying Cabinet
The doors are fitted with a cremone bolt, either right- handed or left-handed. 3.1.2 Capacity 36 hoses or 9 DIN baskets or 9 shelves or SPRI I racks or 18 hoses and 8 shelves with SPRI II racks. USER MANUAL GETINGE DRYING CABINET S-363 9 (24) -
Page 10: Installation
4.1 Free-standing model Secure the machine firmly to the wall with two screws through the holes A at the top of the machine. 10 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 11: Manual Discharge Damper
A. Wall hung singel door model, S-363E B. Recessed two door pass-through version, hole in wall must be 615x2190 Handle Handle Discharge damper Discharge damper For ventilation requirements, see section 3 TECHNICAL DATA. USER MANUAL GETINGE DRYING CABINET S-363 11 (24) -
Page 12: Electrical Installation
• The switch must be easily accessible on a wall close to the machine. • The installation must conform to and be marked in accordance with local regulations. 12 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 13: Connection Diagram
5 ELECTRICAL INSTALLATION 5.1.3 Connection diagram 3N+PE 3+PE -X50 -X50 5.1.4 Pre fuse requirements See section 3 TECHNICAL DATA. USER MANUAL GETINGE DRYING CABINET S-363 13 (24) -
Page 14: Directions For Use
After displaying the temperature for 2 minutes the display window will revert to showing the count-down drying time. 14 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 15: Error Code 1
The control panel can be cleaned in the same way. Remove marks with ordinary stain- remover for stainless steel. USER MANUAL GETINGE DRYING CABINET S-363 15 (24) -
Page 16: Cleaning The Filter Cassette
7 ERROR CODE 1 7.3 Cleaning the filter cassette WARNING! Maintenance must only be done by authorized personnel. WARNING! Before starting work, make sure that the machine is disconnected from the electric power supply. 16 (24) USER MANUAL GETINGE DRYING CABINET S-363... -
Page 17: Overheating Cut-Out
If the heating fails to work, or the fan fails to start, the over-heating cut-out may have tripped. Remove front panel A. Reset the cut-out by pressing red button B. USER MANUAL GETINGE DRYING CABINET S-363 17 (24) -
Page 18: Addresses
3-9-2 Tatsumi, Biezenwei 21 00148 Rome Koto-ku, Tokyo 4004 MB Tiel Italy 135-0053 JAPAN The Netherlands Phone: +39-06 656 631 Phone: +81-3-6758-2280 Phone: +31 (0)344-809900 E-mail: Fax: +31 (0)344-640885 info@getinge-it E-mail: info@getinge.nl 18 (24) USER MANUAL GETINGE DRYING CABINET S-363... - Page 19 Getinge UK Ltd Getinge USA Inc. 1 Pembroke Avenue, 1777 East Henrietta Road Waterbeach Rochester, NY 14623-3133 Cambridge, CB25 9QP United Kingdom Phone: +1-800-475-9040 Phone: +44 (0) 1223 861665 E-mail: E-mail: info.northamerica@getinge.com sales@getinge.co.uk USER MANUAL GETINGE DRYING CABINET S-363 19 (24)
-
Page 21: Alphabetical Index
Overheating cut-out ......................17 Pre fuse requirements ..................... 13 Product liability ........................5 SAFETY INSTRUCTIONS ....................6 TECHNICAL DATA ......................8 USER MANUAL ........................ 1 Warning symbols ....................... 7 Warranty ..........................5 USER MANUAL GETINGE DRYING CABINET S-363 21 (24) - Page 24 www.getinge.com...
