| 13 | Technical specifications
Gas volumes, flows and leakages associated with the breathing system are stated in the
technical specifications and adhere to BTPS reference conditions. (Body temperature, ambient
pressure, Saturated).
All gas concentration readings are normally referenced to dry gas conditions, ambient room
temperature and atmospheric pressure (ATPD).
The condition for measured inlet gas pressures and flows is STPD (Standard Temperature and
Pressure Dry); 20° C, standard pressure at 101.3 kPa and 0 % relative humidity (dry).

13.1 System properties

Weight and dimensions
Base system weight (out of the box
weight)
System nominal weight
System max weight including maximum
load
Dimensions of base plate
Height (1 drawer)
Height (2 drawers)
Height (3 drawers)
Drawers
Vertical shafts for optional horizontal rails
Wheels
Working surface/writing table
Additional writing table
Reading lamp
Display
Type
Size
Placement
Viewing area
Waveforms
Trends
22. Equipped with two full vaporizers, two gas outlets, one auxiliary O2 and suction module, two rails, two rail clamps,
one absorber, breathing tubes, and one patient monitor.
266
|
C20
138 kg (2 drawers)
143 kg (3 drawers)
22
164 kg (2 drawers)
169 kg (3 drawers)
353 kg (2 drawers)
363 kg (3 drawers)
27.2" x 38.8"
N/A
33.9"
40.6"
2-3 (1 lockable)
4
Four wheels
(diameter 5.9") with
separate brakes
Approx. 16.5" x 23.6"
15.6" x 9.8"
Adjustable LED light integrated into the display arm
LED touch screen, complete with 11 membrane switches and one
rotary knob
17.0" x 11.6"
Attached to display arm
15"
Up to 6 waveforms, user configurable
• Graphic display, 1 to 24 hour resolution
• Numeric display, 1 to 60 minute resolution
C30 C40
140 kg 140 kg
166 kg 166 kg
243 kg 273 kg
27.2" x 38.8" 16.0" x 35.3"
(measured over
table-top and grips)
32.9" - 40.4" 24.9"
(adjustable)
N/A 31.6"
N/A N/A
1 (lockable) 1-2 (1 lockable)
4 4
Four wheels Three wheels
(diameter 5.9") with (diameter 2.0")
separate brakes
