HYDRAULIC SYSTEM
11
Item
1 Port 5A - Cab Tilt
2 Port 5B - Cab Tilt
3 Port 4A - Counterweight Removal Pin
4 Port 4B - Counterweight Removal Pin
5 Port 3A - Counterweight Removal Right Cyl.
6 Port 3B - Counterweight Removal Right Cyl.
7 Port 2A - Counterweight Removal Left Cyl.
2-38
12
1, 2
3, 4
5, 6, 7,8
9, 10
9
7
5
3
7
9 10 8
Counterweight Removal/Cab Tilt Directional Valve
Description
Published 11-22-2016, Control # 345-12
11
11
10
8
6
4
2
12
1
13
3 4
5 6
Item
8 Port 2B - Counterweight Removal Left Cyl.
9 Port 1A - Luffing Jib
10 Port 1B - Luffing Jib
11 Inlet
12 Outlet
13 Load Sense Relief
RT9130E-2 SERVICE MANUAL
1 2
Description
12
13
FIGURE 2-20
