Steering And Suspension - Manitowoc Grove RT9130E-2 Service And Maintenance Manual

RT9130E-2 SERVICE MANUAL

Steering and Suspension

Lube Point
Item
Description
Steer Cylinder
1
Pivot Pins
Upper and Lower
2
King Pins
NOTE:
• Grease the top side bearing of the king pin with the crane on rubber until the grease is observed oozing from the
bearing.
• Grease the bottom side bearing of the king pin with the crane on outriggers (wheels have no contact with ground) until
the grease is observed oozing from the bearing.
• After greasing the bushings, turn/steer the hub ends a few times without load (crane on out riggers).
Fifth Wheel
3
Pivots
Lockout Cylinder
4
Pivot Pins
Tie Rod Pivot
5
Pins
Grove
Figure Approved
No. Lubricant
EP-MPG
Extreme
Pressure
Figure 9-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 9-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 9-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 9-1
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 9-1
Multipurpose
Grease
6829003477
Published 11-22-2016, Control # 345-12
Lube
Lube Interval
Capacity
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
Until
grease 500 hours or 3 months
extrudes
LUBRICATION
Application
8 grease fittings
8 grease fittings
2 grease fittings
4 grease fittings
4 grease fittings
9
9-7
