BOOM
Item
1 Base Section
2 Inner Mid Section
3 Center Mid Section
4 Outer Mid Section
5 Fly Section
6 Upper Telescope Cylinder
7 Lower Telescope Cylinder
8 Extend Sheave Mounting Assembly
9 Upper Cylinder Support Foot
10 Wear Pads
11 Extend Sheave Assembly
12 Extend Sheave Shaft With Grease Fitting
13 Extend Sheave Shaft Plate
14 Cable Retainer
15 Cable Guide
16 Extend Cables
17 Retract Cables
18 Skid Pad
19 Lower Cylinder Mount
20 Lower Cylinder Mount Shaft
4-10
Description
Published 11-22-2016, Control # 345-12
RT9130E-2 SERVICE MANUAL
Item
21 Upper Cylinder Support
22 Wear pad Support
23 Shims
24 Cable Pads
25 RCL Cable Mounting Angles
26 Cable Guide Assembly
27 Upper Boom Nose Sheaves
28 Lower Boom Nose Sheaves
29 Cable Retainer Pins
30 Sheave Shaft/Boom Extension Anchor Lugs
31 A2B Plate
32 Cable Retainer Bar
33 Bolt
34 Sled Weld
35 Plate Cover
36 Upper Keeper Plates
37 Lower/Side Keeper Plates
38 Wear Pad Assembly
39 Stop block
40 Guide Block
Description
