RT9130E-2 SERVICE MANUAL
Item
1
Capscrew
2
Washer
3
Cap
4
O-ring
5
Head
6
O-ring
Grove
1, 2
5
8
10
Description
Published 11-22-2016, Control # 345-12
3
4
7
6
11
9
7132
Item
Description
7
Spring
8
Bypass Spring
9
Filter Element
10
Bowl
11
Gasket
HYDRAULIC SYSTEM
FIGURE 2-4
2-13
2
