2.2.6
8
LVDS Resolution Jumper
Jumper
Resolution
Setting
8 800 x 600
1
1024 x 768
8
1
1024 x 768
8
1
8 1024 x 600
1
8 1280 x 800
1
8 1280 x 960
1
8
1280 x 1024
1
8 1366 x 768
1
27
www.gigaipc.com

LSW (LVDS resolution jumper)

Jumper
Resolution
Setting
8 1366 x 768
18bit
1
1440 x 900
8
18bit
1
1400 x 1050
8
24bit
1
1600 x 900
8
18bit
1
1680 x 1050
8
18bit
1
1600 x 1200
8
18bit
1
8 1920 x 1080
24bit
1
1920 x 1200
8
18bit
1
Connector PN
222-97-04GBE1
24bit
24bit
24bit
24bit
24bit
24bit
24bit
24bit
Pin 1
Vendor
PINREX
