No
1
FP_AUDIO
2
SPKR
3
PCIEX16
4
LGA1151
5
BATTERY
6
EDP
7
LVDS
8
LSW
9
JCOM11
10
JRS11-14
11
BKL_CN
19
www.gigaipc.com
40
Code
Front audio header
Speaker out connector
PCIE x16 slot
Intel® LGA1151 socket
Battery cable connector
Embedded Display Port connector
LVDS connector
LVDS resolution jumper
RI pin RI/5V/12V select jumper for COM1
port
RS-232/422/485 select jumper for COM1
port
Backlight Control connector
Description
Advertisement
Table of Contents
Need help?
Do you have a question about the mITX-H310A and is the answer not in the manual?
Questions and answers
I cannot find a Dc power in barrel connector for this motherboard
The GIGAIPC mITX-H310A motherboard uses a DC_IN2 connector for power, which is an ATX 2x2 pin power connector, not a standard DC power barrel connector. The connector part numbers are:
- PINREX: 740-81-04TW56
- ATRC: 25104A0400B3-93LF
You should use a compatible ATX 2x2 power connector, not a DC barrel connector, to supply power to this motherboard.
This answer is automatically generated
