1.1
Specifications
Motherboard
Form Factor
CPU
Socket
Chipset
Memory
Ethernet
Video
Audio
Storage
Expansion Slots
15
www.gigaipc.com
mITX-H310A (MH310AI-SI)
Mini-ITX
170W x 170D (mm)
Support for 9th/8th Generation
Intel® Core™ i7/i5/i3, Pentium® and Celeron® processors in the
LGA1151 package
TDP under 65W
L3 cache varies with CPU
1 x LGA 1151
Intel® H310 Express Chipset
2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB
Support Dual channel DDR4 2666/2400 MHz memory modules
2 x GbE LAN Ports (Intel® I219V and Intel® I211AT)
Integrated Graphics Processor - depends on CPU:
1 x HDMI port, supporting a maximum resolution of 4096x2160
@30Hz
1 x DP port, supporting a maximum resolution of 4096x2160
@60Hz
1 x D-Sub port, supporting a maximum resolution of 1920x1200
@60Hz
1 x eDP port, supporting a maximum resolution of 1920x1080
@60Hz
1 x LVDS port, supporting a maximum resolution of 1920x1080
@60Hz
* eDP port is alternative with LVDS port, only one can be worked
at the same time
(2 independent display outputs)
Realtek® Audio Codec
2 x SATA 6Gb/s Ports
1 x PCIe x16 (Gen3 x16)
1 x 2280/2242 M.2 M-Key (SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
