mITX-Q67EB (MQ67EBI-SI)

mITX-Q67EB Mini-ITX Motherboard

User's Manual 1st Ed

1
www.gigaipc.com

Advertisement

Table of Contents
loading

Summary of Contents for GIGAIPC mITX-Q67EB

  • Page 1: Mitx-Q67Eb Mini-Itx Motherboard

    (MQ67EBI-SI) mITX-Q67EB Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com...
  • Page 2: Copyright Notice

    While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein.
  • Page 3: Acknowledgement

    Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com...
  • Page 4: Packing List

    Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity mITX-Q67EB MB SATA cable I/O Shield If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5: About This Document

    (if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com...
  • Page 6: Safety Precautions

    Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com...
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
  • Page 8: Fcc Statement

    Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com...
  • Page 9: China Rohs Requirements (Cn)

    China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○...
  • Page 10: China Rohs Requirement (En)

    China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
  • Page 11: Table Of Contents

    Table Contents mITX-Q67EB Mini-ITX Motherboard User’s Manual 1st Ed Copyright Notice ................2 Acknowledgement ............... 3 Packing List ................... 4 About this Document ..............5 Safety Precautions ............... 6 FCC Statement ................8 China RoHS Requirements (CN) ............ 9 China RoHS Requirement (EN) ........... 10 Chapter 1 - Product Specifications Specifications ...............
  • Page 12 2.2.26 AT_CN (AT/ATX mode select jumper) ......47 2.2.27 M2M (M.2 Slot, M-Key, NGFF-2280) ......48 Chapter 3 – BIOS Introduction ..............50 The Main Menu............. 51 Advanced ..............52 3.3.1 AMT Configuration ............53 3.3.2 TPM Configuration ............57 www.gigaipc.com...
  • Page 13 3.3.10 NVMe Configuration ............. 66 3.3.11 Offboard SATA Controller Configuration ...... 67 3.3.12 Digital IO Port Configuration ........68 3.3.13 Tls Auth Configuration ..........69 Chipset ................70 Security ................. 72 Boot ................75 Save & Exit ..............76 MEBx ................77 www.gigaipc.com...
  • Page 14: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com...
  • Page 15 170.00 31.60 132.08 41.3 73.31 96.96 120.84 142.55 25.70 154.94 96.19 www.gigaipc.com...
  • Page 16: Specifications

    Specifications Motherboard mITX-Q67EB (MQ67EBI-SI) Mini-ITX Form Factor 170W x 170D (mm) Support for 13th/12th Generation Intel® Core™ i9/ i7/ i5/ i3, Pentium® and Celeron® processors in the LGA1700 package TDP under 65W Socket 1 x LGA 1700 Chipset Intel® Q670E Chipset 2 x DDR4 SO-DIMM sockets, Max.
  • Page 17 Motherboard mITX-Q67EB (MQ67EBI-SI) 2 x Audio Jacks (Line out, Mic in) 1 x COM Port (RS-232/422/485 & RI/5V/12V) 1 x HDMI Rear I/O 1 x Display Port 1 x D-Sub 2 x RJ45 LAN Ports 4 x USB 3.2 Gen 1...
  • Page 18: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com...
  • Page 19: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com...
  • Page 20 USB 3.2 Gen 1 Connector USB32_LAN1 GbE LAN port USB 3.2 Gen 1 Connector USB32_LAN2 2.5GbE LAN port MIC_IN Mic In port (Pink) 10 LINE_OUT Line Out port (Green) 11 ATX 24-pin ATX main power connector 12 GPIO_CNT General purpose input/output header www.gigaipc.com...
  • Page 21 Speaker out Connector 26 FP_AUDIO Front Panel Audio header 27 BATTERY Battery Connector 28 JCOM1 RI# pin RI#/5V/12V Select jumper for COM1 port 29 TPM TPM header AT/ATX mode select jumper 30 AT_CN 31 M2M M.2 Slot, M-Key, NGFF-2280 www.gigaipc.com...
  • Page 22: Io Connector Information

    COM1 Port (RS-232/422/485 & RI/5V/12V) 2 COM1 HDMI Connector HDMI_DP Display Port Connector USB 3.2 Gen 1 Connector USB32_LAN1 GbE LAN port USB 3.2 Gen 1 Connector USB32_LAN2 2.5GbE LAN port 9 MIC_IN Mic In port (Pink) 10 LINE_OUT Line Out port (Green) www.gigaipc.com...
  • Page 23: Vga (Vga Port)

    2.2.2 VGA (VGA Port) D-sub Connector Connector PN Vendor DZ11AA1-H5A7-4F FOXCONN D11015S021126N FENYING Pin No. Definition Pin No. Definition Green Blue DDCSDA HSYNC VSYNC DDCSCL www.gigaipc.com...
  • Page 24: Com1 (Com1 Port (Rs-232/422/485 & Ri/5V/12V))

    2.2.3 COM1 (COM1 Port (RS-232/422/485 & RI/5V/12V)) Serial Port Connector Connector PN Vendor DM10151-N5W3-4F FOXCONN RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com...
  • Page 25: Hdmi_Dp (Hdmi + Dp Connector)

    HDMI Connector Pin No. Definition Pin No. Definition Pin No. Definition Pin No. Definition TX0p TX2p TX3n CLKn TX0n TX2n TX1p TX1p AUXp TX1n TX1n TX2p AUXn TX0p Hot Plug Detect Hot Plug TX0n TX2n 3.3V Detect TX3p 3.3V CLKp www.gigaipc.com...
  • Page 26: Usb32_Lan1 (Usb + Gbe Lan Connector)

    Pin No. Definition Pin No. Definition Definition Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description USB3_RX1n USB3_RX2n Orange On 1Gbps data rate USB3_RX1p USB3_RX2p Green On 100Mbps data rate USB3_TX1n USB3_TX2n 10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com...
  • Page 27: Usb32_Lan2 (Usb + 2.5Gbe Lan Connector)

    Pin No. Definition Pin No. Definition Definition Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description USB3_RX1n USB3_RX2n Orange On 2.5Gbps data rate USB3_RX1p USB3_RX2p Green On 1Gbps data rate USB3_TX1n USB3_TX2n 100M&10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com...
  • Page 28: Atx (24-Pin Atx Main Power Connector)

    2.2.7 ATX (24-pin ATX main power connector) Pin 1 ATX power Connector Connector PN Vendor 740-96-245B70 PINREX Connector type 2x12pin connector, pitch 4.2mm Pin No. Definition Pin No. Definition 3.3V 3.3V 3.3V -12V PS_ON Power Good 5VSB 3.3V www.gigaipc.com...
  • Page 29: Gpio_Cnt (General Purpose Input/Out Header)

    GPIO_CNT (General purpose input/out header) Pin 1 GPIO Connector Pin No. Definition SMBus DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 A2004WV-2X06P46 JOINT-TECH GPIO-output_2 Connector type GPIO-input_2 GPIO-output_3 2x6pin connector, pitch 2.0mm GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock www.gigaipc.com...
  • Page 30: Com2 (Com2 Header (Rs-232))

    2.2.9 COM2 (COM2 header (RS-232)) Pin 1 COM 2 header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Pin No. Definition No connect www.gigaipc.com...
  • Page 31: M2E (M.2 Slot, E-Key, Ngff-2230)

    PCIE CLOCKn SUSCLK PCIE Clock Pin No. Definition Pin No. Definition PCIRST Request 3.3V PCIE wake up BT_Disable 3.3V WLAN_DISABLE 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER PCIE_TXp APCI0095-P002A LOTES PCIE_TXn www.gigaipc.com...
  • Page 32: Sys_Fan (System Fan Connector)

    2.2.11 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition www.gigaipc.com...
  • Page 33: Sata4, Sata5,Sata6, Sata7 (Sata 6Gb/S Connector)

    2.2.12 SATA4, SATA5,SATA6, SATA7 (SATA 6Gb/s Connector) SATA 7 SATA 6 SATA 5 SATA 4 SATA 6Gb/s Connector Pin No. Definition SATA 7 SATA 6 SATA 5 SATA 4 www.gigaipc.com...
  • Page 34: Sys_Panel (System Panel Header)

    2.2.13 SYS_PANEL (System Panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition HD-P MPD-P HD-N MPD-N POWER-ON Reset Reserved www.gigaipc.com...
  • Page 35: Clr_Cmos (Clear Cmos Jumper)

    2.2.14 CLR_CMOS (Clear CMOS jumper) Pin 1 Clear CMOS Jumper Connector PN Vendor LCH24- LIONCONN K0324S21C-00 Connector type 1x3pin header, pitch 2.54mm Pin No. Definition Clear CMOS No Connect 1-2 Close: Clear CMOS data. 2-3 Close: Normal Operator (Default setting) www.gigaipc.com...
  • Page 36: Fusb2_1, Fusb2_2, Fusb2_3 (Usb 2.0 Header)

    2.2.15 FUSB2_1, FUSB2_2, FUSB2_3 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type 2x5pin header, pitch 2.54mm Pin No. Definition No Pin www.gigaipc.com...
  • Page 37: Sodimm1, Sodimm2 (2 X Ddr4 So-Dimm Sockets)

    2.2.16 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets) www.gigaipc.com...
  • Page 38: Cpu_Fan (Cpu Fan Connector)

    2.2.17 CPU_FAN (CPU FAN Connector) Pin 1 CPU Fan Connector Connector PN Vendor 744-81-045W11 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition Detect Speed Control www.gigaipc.com...
  • Page 39: Pciex16 (1 X Pcie X16 (Gen4 X16 Bus) Slot)

    2.2.18 PCIEX16 (1 x PCIe x16 (Gen4 x16 Bus) Slot) PCIEX16 connector www.gigaipc.com...
  • Page 40: Cpu Socket (Lga 1700 Socket)

    2.2.19 CPU Socket (LGA 1700 Socket) www.gigaipc.com...
  • Page 41: Atx_12V (8-Pin Atx 12V Power Connector)

    2.2.20 ATX_12V (8-pin ATX 12V power Connector) Pin 1 ATX 12V Connector Connector PN Vendor 740-96-085B61 PINREX Connector type 2x4pin connector, pitch 4.2mm Pin No. Definition +12V +12V +12V +12V www.gigaipc.com...
  • Page 42: Speaker (Speaker Out Connector)

    2.2.21 SPEAKER (Speaker Out Connector) Pin 1 Speaker Out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition SPEAKER L+ SPEAKER L- SPEAKER R- SPEAKER R+ www.gigaipc.com...
  • Page 43: Fp_Audio (Front Panel Audio Header)

    2.2.22 FP_AUDIO (Front Panel Audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Definition Pin Definition MIC-LEFT JACKSENCE DELTECT MIC-RIGHT DELTECT LINE-LEFT LINE-RIGHT www.gigaipc.com...
  • Page 44: Battery (Battery Connector)

    2.2.23 BATTERY (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com...
  • Page 45: Jcom1 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 Port)

    2.2.24 JCOM1 (RI# pin RI#/5V/12V Select jumper for COM1 Port) Pin 1 JCOM1 Jumper Select Connector PN Vendor 210-92-03GB01 PINREX 1-2 Close: PH06R53BAZ000 HORNGTONG 5V (Power COM) Connector type 2x3pin header, pitch 2.54mm 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com...
  • Page 46: Tpm (Tpm Header)

    2.2.25 TPM (TPM header) Pin 1 TPM Module Connector Pin No. Definition Pin No. Definition Connector PN Vendor Clock 3.3V 52M-90-14GBE7 PINREX Reset LCB25-I1424S01C-12 LIONCONN 3.3V Connector type IRQ_SERIAL 2x7pin header, pitch 2.0mm SDIN www.gigaipc.com...
  • Page 47: At_Cn (At/Atx Mode Select Jumper)

    Pin 1 AT/ATX mode select jumper Connector PN Vendor 220-96-03GB001K PINREX PH03N2-7BAN000 HORNGTONG Connector type 1x3pin header, pitch 2.0mm Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com...
  • Page 48: M2M (M.2 Slot, M-Key, Ngff-2280)

    PCIE Clockp PCIE3 TXp 3.3V 3.3V Pin No. Definition Pin No. Definition PCIE2 RXn 3.3V SUSCLK PCIE2 RXp Detect 3.3V 3.3V PCIE2 TXn 3.3V PCIE2 TXp PCIE1 RXn Connector PN Vendor PCIE1 RXp AS0BC21-S40BM-7H FOXCONN APCI0073-P001A LOTES PCIE1 TXn www.gigaipc.com...
  • Page 49: Chapter 3 - Bios

    Chapter 3 Chapter 3 – BIOS www.gigaipc.com...
  • Page 50: Introduction

    Execute command or enter the submenu Increase the numeric value or make + changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...
  • Page 51: The Main Menu

    ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...
  • Page 52: Advanced

    Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...
  • Page 53: Amt Configuration

    Enabled : Enables MAC Pass Through function Trigger CIRA boot Activate Remote Disabled : Disables TPM feature (Default setting) Assistance Process Enabled : Enables TPM feature To Un-configure ME without password. Unconfigure ME Disabled : Disables Unconfigure ME (Default settings) Enabled : Enables Unconfigure ME www.gigaipc.com...
  • Page 54 Disabled : Disables watchdog Timer (Default setting) Enabled : Enables watchdog Timer OS Timer Sets OS Watchdog Timer. BIOS Timer Sets BIOS Timer. Disabled : Disables ASF Sensors Table (Default setting) ASF Sensors Table Enabled : Enables ASF Sensors Table www.gigaipc.com...
  • Page 55 Secure Erase Simulated : Performs SE flow without erasing SSD (Default setting) mode Real : Erase SSD Force Secure Erase on next boot. Force Secure Disabled : Disables Force Secure Erase (Default setting) Erase Enabled : Enables Force Secure Erase www.gigaipc.com...
  • Page 56 Disabled : Disables One Click Recovery Windows recovery boot. Allows CSME to request Secureboot to be disabled for One Click Recovery. OCR Disable Secure Enabled : Enables One Click Recovery disable Secure Boot function. Boot (Default setting) Disabled : Disables One Click Recovery disable Secure Boot function. www.gigaipc.com...
  • Page 57: Tpm Configuration

    3.3.2 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB) www.gigaipc.com...
  • Page 58 Item Description Security Device Enabled : Enables TPM feature (Default setting) Support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TP www.gigaipc.com...
  • Page 59: Cpu Configuration

    Enabled : Enables CPU C states function (Default setting) Disabled : Disables CPU C states function To optimize CPU performance. Dual Tau Boost Enabled : Enables Dual Tau Boost function Disabled : Disables Dual Tau Boost function (Default setting) www.gigaipc.com...
  • Page 60: Sata Configuration

    / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port 4 Serial ATA Port 5 shows 2.5" SATA HDD/SSD information Serial ATA Port 6 Serial ATA Port 7 www.gigaipc.com...
  • Page 61: It8786 Super Io Configuration

    Serial Port 2 Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...
  • Page 62: Hardware Monitor

    Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com...
  • Page 63: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...
  • Page 64: Intel Txt Information

    3.3.8 Intel TXT Information This submenu shows detailed Intel TXT informations. www.gigaipc.com...
  • Page 65: Network Stack Configuration

    Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com...
  • Page 66: Nvme Configuration

    3.3.10 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...
  • Page 67: Offboard Sata Controller Configuration

    3.3.11 Offboard SATA Controller Configuration www.gigaipc.com...
  • Page 68: Digital Io Port Configuration

    Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com...
  • Page 69: Tls Auth Configuration

    Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com...
  • Page 70: Chipset

    Auto : Detects display device automatically (Default setting) Internal Graphics Enabled : Enables onboard graphics Disabled : Disables onboard graphics Enable/Disable onboard LAN controller Onboard LAN1 Enabled : Enables onboard LAN controller (Default setting) Onboard LAN2 Disabled : Disables onboard LAN controller www.gigaipc.com...
  • Page 71 Enable/Disable Watchdog Timer function Watchdog Timer Disabled : Disables Watchdog Timer function (Default setting) Enabled : Enables Watchdog Timer function Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
  • Page 72: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 73 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 74 ’Mi c r o s of t UEFI C A’ MS UEFI CA Key variables files in a root folder on a Certificate in file system device Authorized Signature Allow the image to run in database(db) Enroll Efi Image Secure Boot mode www.gigaipc.com...
  • Page 75: Boot

    Enable/Disable Built-in EFI Shell Built-in EFI Shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com...
  • Page 76: Save & Exit

    Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
  • Page 77: Mebx

    MEBx Item Description Intel(R) ME For MEBx Login Password www.gigaipc.com...
