Page 1: Mitx-H610A Mini-Itx Motherboard
(MH610AI-SI) mITX-H610A Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity mITX-H610A MB SATA power cable I/O Bracket If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
Table Contents mITX-H610A Mini-ITX Motherboard User’s Manual 1st Ed Copyright Notice ................2 Acknowledgement ............... 3 Packing List ................... 4 About this Document ..............5 Safety Precautions ............... 6 FCC Statement ................8 China RoHS Requirements (CN) ............ 9 China RoHS Requirement (EN) ........... 10 Chapter 1 - Product Specifications Specifications ............... - Page 12 2.2.27 TPM (TPM header) ............48 2.2.28 BKL_CN (Backlight Control Connector) ......49 2.2.29 AT_CN (AT/ATX mode select jumper) ......50 2.2.30 M2E (M.2 Slot, E-Key, NGFF-2230) ........ 51 2.2.31 M2M (M.2 Slot, M-Key, NGFF-2280) ......52 Chapter 3 – BIOS Introduction ..............54 www.gigaipc.com...
- Page 13 3.3.9 NVMe Configuration ............. 66 3.3.10 Offboard SATA Controller Configuration ...... 67 3.3.11 Digital IO Port Configuration ........68 3.3.12 Tls Auth Configuration ..........69 Chipset ................70 Security ................. 72 Boot ................75 Save & Exit ..............76 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 www.gigaipc.com...
-
Page 16: Specifications
Specifications Motherboard mITX-H610A (MH610AI-SI) Mini-ITX Form Factor 170W x 170D (mm) Support for 13th/12th Generation Intel® Core™ i9/ i7/ i5/ i3, Pentium® and Celeron® processors in the LGA1700 package TDP under 65W Socket 1 x LGA 1700 Chipset Intel® H610 Chipset 2 x DDR4 SO-DIMM sockets, Max. - Page 17 Motherboard mITX-H610A (MH610AI-SI) 2 x Audio Jacks (Line out, Mic in) 1 x COM Port (RS-232/422/485 & RI/5V/12V) 1 x HDMI 1 x Display Port Rear I/O 1 x D-Sub 2 x RJ45 LAN Ports 4 x USB 3.2 Gen 1...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 20 Display Port Connector USB 3.2 Gen 1 Connector USB32_LAN1 GbE LAN port USB 3.2 Gen 1 Connector USB32_LAN2 2.5GbE LAN port 11 MIC_IN Mic In port (Pink) 12 LINE_OUT Line out port (Green) 13 CPU Socket 1 x LGA 1700 Socket www.gigaipc.com...
- Page 21 Battery Connector RI# pin RI#/5V/12V Select jumper for COM1 30 JCOM1 port 31 TPM TPM header Backlight Control connector 32 BKL_CN 33 AT_CN AT/ATX mode select jumper 34 M2E M.2 Slot, E-Key, NGFF-2230 35 M2M M.2 Slot, M-Key, NGFF-2280 www.gigaipc.com...
-
Page 22: Io Connector Information
COM1 Port (RS-232/422/485 & RI/5V/12V) 3 COM1 HDMI Connector HDMI_DP Display Port Connector USB 3.2 Gen 1 Connector USB32_LAN1 GbE LAN port USB 3.2 Gen 1 Connector USB32_LAN2 2.5GbE LAN port 10 MIC_IN Mic In port (Pink) 11 LINE_OUT Line out port (Green) www.gigaipc.com... -
Page 23: Dc_In1 (Dc In Jack 4 Pin Din)
2.2.2 DC_IN1 (DC In Jack 4 Pin Din) DC In Jack 4 Pin Din Connector PN Vendor 2MJ-3422A1I0 SINGATRON www.gigaipc.com... -
Page 24: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.3 DC_IN2 (ATX 2x2 Pin Power Connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX Pin No. Definition DC IN DC IN www.gigaipc.com... -
Page 25: Vga (Vga Port)
2.2.4 VGA (VGA Port) D-sub Connector Connector PN Vendor DZ11AA1-H5A7-4F FOXCONN D11015S021126N FENYING Pin No. Definition Pin No. Definition Green Blue DDCSDA HSYNC VSYNC DDCSCL www.gigaipc.com... -
Page 26: Com1 (Com1 Port (Rs-232/422/485 & Ri/5V/12V))
2.2.5 COM1 (COM1 Port (RS-232/422/485 & RI/5V/12V)) Serial Port Connector Connector PN Vendor DM10151-N5W3-4F FOXCONN RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com... -
Page 27: Hdmi_Dp (Hdmi + Dp Connector)
HDMI Connector Pin No. Definition Pin No. Definition Pin No. Definition Pin No. Definition TX0p TX2p TX3n CLKn TX0n TX2n TX1p TX1p AUXp TX1n TX1n TX2p AUXn TX0p Hot Plug Detect Hot Plug TX0n TX2n 3.3V Detect TX3p 3.3V CLKp www.gigaipc.com... -
Page 28: Usb32_Lan1 (Usb + Gbe Lan Connector)
Pin No. Definition Pin No. Definition Definition Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description USB3_RX1n USB3_RX2n Orange On 1Gbps data rate USB3_RX1p USB3_RX2p Green On 100Mbps data rate USB3_TX1n USB3_TX2n 10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 29: Usb32_Lan2 (Usb + 2.5Gbe Lan Connector)
Pin No. Definition Pin No. Definition Definition Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description USB3_RX1n USB3_RX2n Orange On 2.5Gbps data rate USB3_RX1p USB3_RX2p Green On 1Gbps data rate USB3_TX1n USB3_TX2n 100M&10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 30: Cpu Socket (Lga 1700 Socket)
2.2.9 CPU Socket (LGA 1700 Socket) www.gigaipc.com... -
Page 31: Lvds (Lvds Connector)
But below model no need to add. SPEC0 A0~A3 is odd channel 0~3, A4~A7 is ev SPED0 en channel. Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN approval CLK2+ equipment with fire enclosure. CLK1+ CLK2- www.gigaipc.com... -
Page 32: Com2 (Com2 Header (Rs-232))
2.2.11 COM2 (COM2 header (RS-232)) Pin 1 COM 2 header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Pin No. Definition No connect www.gigaipc.com... -
Page 33: Sys_Fan (System Fan Connector)
2.2.12 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX Pin No. Definition www.gigaipc.com... -
Page 34: Gpio_Cnt (General Purpose Input/Out Header)
2.2.13 GPIO_CNT (General purpose input/out header) Pin 1 GPIO Connector Pin No. Definition SMBus Clock SMBus DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 A2004WV-2X06P46 JOINT-TECH GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 www.gigaipc.com... -
Page 35: Buzzer (Buzzer Header)
2.2.14 BUZZER (Buzzer header) Pin 1 Buzzer Connector PN Vendor 712-71-02TW01 PINREX A1250WV-02P JOINT-TECH Pin No. Definition Buzzer www.gigaipc.com... -
Page 36: Sata_Pwr (Sata Power Connector)
2.2.15 SATA_PWR (SATA Power Connector) Pin 1 SATA Power Connector Connector PN Vendor 743-81-04TW00 PINREX Pin No. Definition www.gigaipc.com... -
Page 37: Sata4, Sata5 (Sata 6Gb/S Connector)
2.2.16 SATA4, SATA5 (SATA 6Gb/s Connector) SATA 4 SATA 5 SATA 6Gb/s Connector Pin No. Definition SATA 4 SATA 5 www.gigaipc.com... -
Page 38: Sys_Panel (System Panel Header)
2.2.17 SYS_PANEL (System Panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Pin No. Definition HD-P MPD-P HD-N MPD-N POWER-ON Reset Reserved www.gigaipc.com... -
Page 39: Clr_Cmos (Clear Cmos Jumper)
2.2.18 CLR_CMOS (Clear CMOS jumper) Pin 1 Clear COMS Jumper Connector PN Vendor 212-91-03GBE00K PINREX Pin No. Definition Clear CMOS No Connect 1-2 Close: Clear COMS data. 2-3 Close: Normal Operator (Default setting) www.gigaipc.com... -
Page 40: Fusb2_1, Fusb2_2 (Usb 2.0 Header)
2.2.19 FUSB2_1, FUSB2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin www.gigaipc.com... -
Page 41: Sodimm1, Sodimm2 (2 X Ddr4 So-Dimm Sockets)
2.2.20 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets) www.gigaipc.com... -
Page 42: Cpu_Fan (Cpu Fan Connector)
2.2.21 CPU_FAN (CPU FAN Connector) Pin 1 CPU Fan Connector Connector PN Vendor 744-81-045W11 PINREX Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 43: Pciex16 (1 X Pcie X16 (Gen4 X16 Bus) Slot)
2.2.22 PCIEX16 (1 x PCIe x16 (Gen4 x16 Bus) Slot) PCIEX16 connector www.gigaipc.com... -
Page 44: Spkr (Speaker Out Connector)
2.2.23 SPKR (Speaker Out Connector) Pin 1 Speaker Out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition SPEAKER L+ SPEAKER L- SPEAKER R- SPEAKER R+ www.gigaipc.com... -
Page 45: Fp_Audio (Front Panel Audio Header)
2.2.24 FP_AUDIO (Front Panel Audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC-LEFT JACKSENCE DELTECT MIC-RIGHT DELTECT LINE-LEFT LINE-RIGHT www.gigaipc.com... -
Page 46: Battery (Battery Connector)
2.2.25 Battery (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com... -
Page 47: Jcom1 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 Port)
2.2.26 JCOM1 (RI# pin RI#/5V/12V Select jumper for COM1 Port) Pin 1 JCOM1 Jumper Select Connector PN Vendor 210-92-03GB01 PINREX 1-2 Close: PH06R53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 48: Tpm (Tpm Header)
2.2.27 TPM (TPM header) Pin 1 TPM Module Connector Pin No. Definition LFRAME Pin No. Definition Connector PN Vendor LPCCLK 3.3V 52M-90-14GBE7 PINREX TPM RST LCB25-I1424S01C-12 LIONCONN 3.3V LAD0 IRQ_SERIAL LAD1 TPM_DET LAD2 LAD3 www.gigaipc.com... -
Page 49: Bkl_Cn (Backlight Control Connector)
2.2.28 BKL_CN (Backlight Control Connector) Pin 1 Backlight Control Connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition 5V (12V optional) Backlight enable www.gigaipc.com... -
Page 50: At_Cn (At/Atx Mode Select Jumper)
2.2.29 AT_CN (AT/ATX mode select jumper) Pin 1 AT/ATX mode select jumper Connector PN Vendor 220-96-03GB001K PINREX PH03N2-7BAN000 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 51: M2E (M.2 Slot, E-Key, Ngff-2230)
PCIE CLOCKn SUSCLK PCIE Clock PCIRST Pin No. Definition Pin No. Definition Request 3.3V PCIE wake up BT_Disable 3.3V WLAN_DISABLE 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER PCIE_TXp APCI0095-P002A LOTES PCIE_TXn CL_Reset www.gigaipc.com... -
Page 52: M2M (M.2 Slot, M-Key, Ngff-2280)
PCIE Clockp PCIE3 TXp 3.3V 3.3V Pin No. Definition Pin No. Definition PCIE2 RXn 3.3V SUSCLK PCIE2 RXp Detect 3.3V 3.3V PCIE2 TXn 3.3V PCIE2 TXp PCIE1 RXn Connector PN Vendor PCIE1 RXp AS0BC21-S40BM-7H FOXCONN APCI0073-P001A LOTES PCIE1 TXn www.gigaipc.com... -
Page 53: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 54: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 55: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 56: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 57: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB) www.gigaipc.com... - Page 58 Item Description Security Device Enabled : Enables TPM feature (Default setting) Support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 59: Cpu Configuration
Enabled : Enables CPU C states function (Default setting) Disabled : Disables CPU C states function To optimize CPU performance. Dual Tau Boost Enabled : Enables Dual Tau Boost function Disabled : Disables Dual Tau Boost function (Default setting) www.gigaipc.com... -
Page 60: Sata Configuration
3.3.3 SATA Configuration Item Description Serial ATA Port 4 shows 2.5" SATA HDD/SSD information Serial ATA Port 5 www.gigaipc.com... -
Page 61: It8786 Super Io Configuration
Serial Port 2 Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com... -
Page 62: Hardware Monitor
Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com... -
Page 63: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 64: Ami Graphic Output Protocol Policy
3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com... -
Page 65: Network Stack Configuration
Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com... -
Page 66: Nvme Configuration
3.3.9 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 67: Offboard Sata Controller Configuration
3.3.10 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 68: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 69: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : Enroll Cert 1. Enroll Cert Using File 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 70: Chipset
Enable/Disable onboard LAN controller Onboard LAN1 Enabled : Enables onboard LAN controller (Default setting) Onboard LAN2 Disabled : Disables onboard LAN controller Enable/Disable onboard audio controller HD Audio Enabled : Enables onboard audio controller (Default setting) Disabled : Disables onboard audio controller www.gigaipc.com... - Page 71 Enable/Disable Watchdog Timer function Watchdog Timer Disabled : Disables Watchdog Timer function (Default setting) Enabled : Enables Watchdog Timer function Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
-
Page 72: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 73 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 74 These items allows you to enroll factory defaults or load Certificates from a Forbidden Signatures file. Authorized TimeStamps OsRecovery Signatures Device Guard ready system must not list ’Microsoft UEFI CA’ Certificate in MS UEFI CA Key Authorized Signature database(db) www.gigaipc.com...
-
Page 75: Boot
Enable/Disable Built-in EFI Shell Built-in EFI Shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 76: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
