Page 1: Thin Mini-Itx Motherboard
(MH310AI-SI) Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity mITX-H310A MB SATA power cable I/O Bracket If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
EDP (Embedded Display Port Connector) ..... 24 2.2.5 LVDS (LVDS connector) ..........25 2.2.6 LSW (LVDS resolution jumper) ........26 2.2.7 JCOM11 (COM1 RI pin RI/5V/12V Select jumper) ..27 2.2.8 JRS 11-14 (COM1 JRS11-14 select jumper for serial port) ..................28 www.gigaipc.com... - Page 12 2.2.22 COM2 (Serial Port header) ..........42 2.2.23 SYS_PANEL (Front Panel header) ........ 43 2.2.24 F_USB 2_1 (USB 2.0 header) ......... 44 2.2.25 F_USB 2_2 (USB 2.0 header) ......... 45 2.2.26 CPU_FAN (CPU fan connector) ........46 2.2.27 DC_IN (DC In JACK Connector) ........47 www.gigaipc.com...
-
Page 13: Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 www.gigaipc.com...
-
Page 15: Specifications
Specifications Motherboard mITX-H310A (MH310AI-SI) Mini-ITX Form Factor 170W x 170D (mm) Support for 8th/9th Generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/ Intel® Pentium®processors/Intel® Celeron® processors in the LGA1151 package, TDP under 65W L3 cache varies with CPU... - Page 16 Motherboard mITX-H310A (MH310AI-SI) 1 x 4-pin ATX main power connector 2 x SATA 6Gb/s connectors 1 x SATA power connectors 1 x CPU fan header 1 x System fan header 1 x Front panel header 1 x Front panel audio header 4 x USB 2.0/1.1 headers...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors 30 29 28 27 Code Description F_AUDIO Front audio header SPK_OUT Speaker out connector PCIE16X PCIE x16 slot Intel® LGA1151 socket BATTERY Battery cable connector Embedded Display Port connector www.gigaipc.com... - Page 19 ATX Control header JCOM16 COM16 RI pin RI/5V/12V Select CLR_CMOS Clear CMOS jumper JRS21-24 COM2 JRS21-24 select jumper for serial port COM2 Serial port header SYS_PANEL Front panel header FUSB2_1 USB 2.0 header FUSB2_2 USB 2.0 header CPU_FAN CPU fan connector www.gigaipc.com...
- Page 20 USB30_LAN2 2 USB 3.0 ports + GbE LAN port USB30_LAN1 2 USB 3.0 ports + GbE LAN port AUDIO JACK 3 x Audio jacks (Line in, Line out, Mic in) M2_M Port 1 x M.2 Slot 2242/2280 Storage SATA www.gigaipc.com...
-
Page 21: F_Audio (Front Audio Header)
2.2.1 F_Audio (Front audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L MIC_R No Connect Detect HPOUT_L HPOUT_R www.gigaipc.com... -
Page 22: Spk_Out (Speaker Out Connector)
2.2.24 SPK_OUT (Speaker out Connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 23: Battery
2.2.3 Battery Pin 1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com... -
Page 24: Edp (Embedded Display Port Connector)
Pin 1 Note: * Please ensure pin 8 is Embedded Display Port connector connected to Ground. Connector PN Vendor Definition Pin Definition A1252WV-SF- JOINT-TECH 2X10PN6BG1G00L eDP_1+ 50286-02071-001 ACES eDPAUX- eDP_0- eDP_3- eDPAUX+ eDP_0+ eDP_2- eDP_3+ eDP_2+ eDPSW * eDP_1- 3.3V www.gigaipc.com... -
Page 25: Lvds (Lvds Connector)
2.2.5 LVDS (LVDS connector) Pin 1 LVDS Connector Pin No. Definition Pin No. Definition CLK1- Pin No. Definition Pin No. Definition 3.3V Connector PN Vendor 3.3V 712-76-40GWE0 PINREX SPEC0 A1252WV-SF-2X20PD01 JOINT-TECH SPED0 CLK2+ CLK1+ CLK2- www.gigaipc.com... -
Page 26: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 27: Jcom11 (Com1 Ri Pin Ri/5V/12V Select Jumper)
2.2.7 JCOM11 (COM1 RI pin RI/5V/12V Select jumper) Pin 1 JCOM11 Jumper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM)(Default) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 28: Jrs 11-14 (Com1 Jrs11-14 Select Jumper For Serial Port)
RS-485 Half Duplex 1T/1R RS-485, TX ENABLE Low Active RS-485 Half Duplex 1T/1R RS-485, TX ENABLE High Active RS-422 Full Duplex 1T/1R RS-422 with termination resistor and bias resistor. 1T/1R RS-485 with termination resistor and bias resistor. RS-485 Half Duplex TX ENABLE Low Active www.gigaipc.com... -
Page 29: Bkl_Cn (Back Light Brightness Control Connector)
2.2.9 BKL_CN (Back light brightness control connector) Pin 1 Back light brightness control Connector PN Vendor connector 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com... -
Page 30: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.10 DC_IN2 (ATX 2x2 pin power connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX 25104A0400B3-93LF ATRC Pin No. Definition +12V +12V www.gigaipc.com... -
Page 31: Com4 (Serial Port Header)
2.2.11 COM4 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... -
Page 32: Com3 (Serial Port Header)
2.2.12 COM3 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... -
Page 33: Sys_Fan (System Fan Connector)
2.2.13 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 34: Gpio_Cnt (Gpio Connector)
2.2.14 GPIO_CNT (GPIO Connector) Pin 1 GPIO Connector Pin No. Definition SMB_CLK SMB_DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPO1 GPI1 A2004WV-2X06P46 JOINT-TECH GPO2 GPI2 GPO3 GPI3 GPO4 GPI4 www.gigaipc.com... -
Page 35: Tpm_Lpc (Trusted Platform Module Connector)
2.2.15 TPM_LPC (Trusted Platform Module Connector) Pin 1 TPM Module Connector Pin No. Definition TPM_DET LAD2 LAD3 Pin No. Definition LFRAME LPCCLK 3VDUAL PFM RST VCC3 Connector PN Vendor LAD0 52M-90-14GBE7 PINREX IRQ_SERIAL LAD1 www.gigaipc.com... -
Page 36: Satapw (Sata 6Gb/S Power Connector)
2.2.16 SATAPW (SATA 6Gb/s Power Connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 37: Sataiii_0, Sataiii_1 (Sata 6Gb/S Connector)
2.2.17 SATAIII_0, SATAIII_1 (SATA 6Gb/s Connector) 20 21 Pin 1 SATA Connector SATAIII_1, SATAIII_0 Connector PN Vendor WATM-07ABNB2BAUW3 WINWIN SATA 0 SATA 1 770-83-07SW19 PINREX Definition Pin Definition www.gigaipc.com... -
Page 38: Atx_Crl (Atx Control Header)
2.2.18 ATX_CRL (ATX Control header) Pin 1 ATX Control Header Pin No. Definition ATX_PSON ATX_5VSB www.gigaipc.com... -
Page 39: Jcom16 (Com2 Ri Pin Ri/5V/12V Select)
2.2.19 JCOM16 (COM2 RI pin RI/5V/12V Select) Pin 1 JCOM16 Jumper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM)(Default) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 40: Clr_Cmos (Clear Cmos Jumper)
2.2.20 CLR_CMOS (Clear CMOS Jumper) Pin 1 Clear COMS Jumper Connector PN Vendor 210-91-02GB01 PINREX PH02R23BAZ000 HORNGTONG Pin No. Definition Clear CMOS Open: Normal Operation (Default setting) Close: Clear COMS data. www.gigaipc.com... -
Page 41: Jrs21-24 (Com2 Jrs21-24 Select Jumper For Serial Port)
RS-485 Half Duplex 1T/1R RS-485, TX ENABLE Low Active RS-485 Half Duplex 1T/1R RS-485, TX ENABLE High Active RS-422 Full Duplex 1T/1R RS-422 with termination resistor and bias resistor. 1T/1R RS-485 with termination resistor and bias resistor. RS-485 Half Duplex TX ENABLE Low Active www.gigaipc.com... -
Page 42: Com2 (Serial Port Header)
2.2.22 COM2 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... -
Page 43: Sys_Panel (Front Panel Header)
2.2.23 SYS_PANEL (Front Panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 44: F_Usb 2_1 (Usb 2.0 Header)
2.2.24 F_USB 2_1 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 45: F_Usb 2_2 (Usb 2.0 Header)
2.2.25 F_USB 2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 46: Cpu_Fan (Cpu Fan Connector)
2.2.26 CPU_FAN (CPU fan connector) Pin 1 CPU FAN Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 47: Dc_In (Dc In Jack Connector)
2.2.27 DC_IN (DC In JACK Connector) DC JACK Connector Connector PN Vendor 2MJ-3422A1I0 SINGATRON www.gigaipc.com...
