Summary of Contents for GIGAIPC mITX-1605A
-
Page 1: Thin Mini-Itx Motherboard
(MRZNVMI) Thin Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity mITX-1605A MB SATA power cable I/O Bracket mITX-V1000 Fan Sink If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 4: Assembly Sequence
According to the above assembly sequence, the correct 2>. torque is used to lock the heat sink. When removing, please reverse (spinning from position 4) 3>. to remove www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
................21 2.2.3 DP3_4, DP1_2 (Display ports) ........22 2.2.4 COM1_2 (Serial ports) ..........22 2.2.5 DC_IN (DC In JACK Connector) ........23 2.2.6 DC_IN2 (ATX 2x2 pin power connector) ....... 24 2.2.7 SYS_FAN (System Fan Connector) ........ 25 www.gigaipc.com... - Page 12 2.2.26 M2E (M.2 E-key) ............44 2.2.27 MPCIE (Mini PCI-E) ............45 2.2.28 BKL_CN (Back light brightness control connector) ..46 2.2.29 LVDS (LVDS connector) ..........47 2.2.30 JCOM1, JCOM2 (COM1 & COM2 RI# pin RI#/5V/12V Select) ................. 48 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 www.gigaipc.com...
-
Page 15: Specifications
1 x PCIe x16 (X8 bus) slot 1 x Mini PCIe (Full Size PCIe & USB) 1 x M.2 slot: - M-key Expansion Slots - SATA 6Gb/s - Supports NGFF-2280 cards 1 x M.2 slot: - E-key - Supports NGFF-2230 Combo cards www.gigaipc.com... - Page 16 Non-operating temperature: -20°C to 70°C Non-operating humidity: 0%-95% (non-condensing) BOX Packing Capacity: 10pcs Carton size: 551 x 470 x 230 (mm) Content: Packing Content IO Shield x 1 (12AIO-MRZNV0-00R) SATA Power cable x 1 (25CRI-200B02-K1R) Fansink x 1 (12SF2-01A077-00R) www.gigaipc.com...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors 26 27 www.gigaipc.com... - Page 19 14 SYS_PANEL Front panel header 15 TPM_LPC TPM connector 16 SODIMM1, SODIMM2 DDR4 SO-DIMM slot#1/slot#2 17 CLR_CMOS Clear CMOS jumper 18 CPU_FAN CPU fan connector 19 M2_M M.2 M-key 20 PCIE16X PCIE x16 slot 21 SPK_OUT Speaker out connector www.gigaipc.com...
- Page 20 Battery cable connector 24 LVDS_DP LVDS/DP Jumper 25 LSW LVDS resolution jumper 26 M2E M.2 E-key 27 MINI_PCIE MINI PCIE connector 28 BKL_CN Back light brightness control connector 29 LVDS LVDS connector 30 JCOM1, JCOM2 COM1/2 RI# pin RI#/5V/12V Select www.gigaipc.com...
-
Page 21: Audio (Audio Line-Out Port)
2.2.1 AUDIO (Audio line-out port) 2.2.2 USB3_LAN2, USB3_LAN1 (USB 3.0 ports + Gbe LAN port) www.gigaipc.com... -
Page 22: Dp3_4, Dp1_2 (Display Ports)
2.2.3 DP3_4, DP1_2 (Display ports) 2.2.4 COM1_2 (Serial ports) www.gigaipc.com... -
Page 23: Dc_In (Dc In Jack Connector)
2.2.5 DC_IN (DC In JACK Connector) www.gigaipc.com... -
Page 24: Dc_In2 (Atx 2X2 Pin Power Connector)
2.2.6 DC_IN2 (ATX 2x2 pin power connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX 25104A0400B3-93LF ATRC Pin No. Definition +12V ~ +24V +12V ~ +24V www.gigaipc.com... -
Page 25: Sys_Fan (System Fan Connector)
2.2.7 SYS_FAN (System Fan Connector) Pin 1 System FAN Connector PN Vendor 744-81-045R11 PINREX WF04R22RJQ105 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 26: Sata1 (Sata 6Gb/S Connector)
2.2.8 SATA1 (SATA 6GB/S Connector) SATA Connector SATAIII_1,SATAIII_0 Connector PN Vendor WATM-07ABNB2BAUW3 WINWIN 770-83-07SW19 PINREX SATAIII_2 Connector PN Vendor Definition Pin Definition ASAT0014-P008C LOTES www.gigaipc.com... -
Page 27: Satapw1 (Sata 6Gb/S Power Connector)
2.2.9 SATAPW1 (SATA 6GB/S Power Connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 28: F_Usb2_3, F_Usb2_1, F_Usb2_2 (Usb 2.0 Header)
2.2.10 F_USB2_3, F_USB2_1, F_USB2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Pin No. Definition No Pin Pin No. Definition No Connect Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG www.gigaipc.com... -
Page 29: Com3, Com4 (Serial Port Header)
2.2.11 COM3, COM4 (Serial Port header) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect www.gigaipc.com... -
Page 30: At_Cn (At/Atx Power Mode Select Jumper)
2.2.12 AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Connector PN Vendor PH03N33BAAA00 HORNGTONG Pin No. Definition AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode. (Default setting) www.gigaipc.com... -
Page 31: Gpio_Cnt (General Purpose Input/Output Connector)
2.2.13 GPIO_CNT (General purpose input/output connector) Pin 1 GPIO Connector Pin No. Definition GPO4 GPI4 SMB_CLK SMB_DATA Pin No. Definition Connector PN Vendor GPO1 725-81-12TW00 PINREX GPI1 A2004WV-2X06P46 JOINT-TECH GPO2 GPI2 GPO3 GPI3 www.gigaipc.com... -
Page 32: Sys_Panel (Front Panel Header)
2.2.14 SYS_PANEL (Front Panel Header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 33: Tpm_Lpc (Trusted Platform Module Connector)
2.2.15 TPM_LPC (Trusted Platform Module Connector) Pin 1 TPM Module Connector Pin No. Definition LAD3 LFRAME Pin No. Definition Connector PN Vendor LPCCLK 3VDUAL 52M-90-14GBE7 PINREX TPM RST VCC3 LAD0 IRQ_SERIAL LAD1 TPM_DET LAD2 www.gigaipc.com... -
Page 34: Sodimm1, Sodimm2 (Ddr4 So-Dimm Slot#1/Slot#2)
2.2.16 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot#1/ slot#2) www.gigaipc.com... -
Page 35: Clr_Cmos (Clear Cmos Jumper)
2.2.17 CLR_CMOS (Clear CMOS jumper) Pin 1 Clear COMS Jumper Connector PN Vendor 210-91-02GB01 PINREX PH02R23BAZ000 HORNGTONG Pin No. Definition RTCVDD_C No Connect 1-2 Close: Clear COMS data. 2-3 Close: Normal Operator (Default setting) www.gigaipc.com... -
Page 36: Cpu_Fan (Cpu Fan Connector)
2.2.18 CPU_FAN (CPU fan connector) Pin 1 CPU FAN Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 37: M2M (M.2 M-Key)
2.2.19 M2M (M.2 M-key) www.gigaipc.com... -
Page 38: Pciex16 (Pcie X16 Slot)
2.2.20 PCIEX16 (PCIE x16 slot) www.gigaipc.com... -
Page 39: Spk_Out (Speaker Out Connector)
2.2.21 SPK_OUT (Speaker out Connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out R+ Speaker Out R- Speaker Out L- Speaker Out L+ www.gigaipc.com... -
Page 40: F_Audio (Front Audio Header)
2.2.22 F_Audio (Front audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L Detect FAUDIO_JD MIC_R No Connect Detect HPOUT_L HPOUT_R Detect www.gigaipc.com... -
Page 41: Bat (Battery Cable Connector)
2.2.23 BAT (Battery Cable connector) Pin 1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com... -
Page 42: Lvds_Dp (Lvds/Dp Jumper)
2.2.24 LVDS_DP (LVDS/DP jumper) Pin 1 LVDS_DP Jumper Connector PN Vendor 200-72-PBGB03 PINREX Pin No. Definition No Connect GPU_SEL 1-2 Close: DP4 DP Mode (Default) 2-3 Close: DP4 LVDS Mode www.gigaipc.com... -
Page 43: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 44: M2E (M.2 E-Key)
2.2.26 M2E (M.2 E-key) www.gigaipc.com... -
Page 45: Mpcie (Mini Pci-E)
2.2.27 MPCIE (Mini PCI-E) www.gigaipc.com... -
Page 46: Bkl_Cn (Back Light Brightness Control Connector)
2.2.28 BKL_CN (Back light brightness control connector) Pin 1 Back light brightness control Connector PN Vendor connector 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com... -
Page 47: Lvds (Lvds Connector)
2.2.29 LVDS (LVDS connector) Pin 1 Pin 1 LVDS Connector Pin No. Definition Pin No. Definition CLK2+ CLK1+ CLK2- Pin No. Definition Pin No. Definition CLK1- 3.3V 3.3V SPEC0 SPED0 Connector PN Vendor 712-76-40GWE0 PINREX A1252WV-SF-2X20PD01 JOINT-TECH www.gigaipc.com... -
Page 48: Jcom1, Jcom2 (Com1 & Com2 Ri# Pin Ri#/5V/12V Select)
2.2.30 JCOM1, JCOM2 (COM1 & COM2 RI# pin RI#/5V/12V Select) Pin 1 JCOM1, JCOM2 Jummper Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM)(Default) 5-6 Close: 12V (Power COM) www.gigaipc.com...
