mITX-6412A (MEHLJAI-SI)

mITX-6412A Mini-ITX Motherboard

User's Manual 1st Ed
1
www.gigaipc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mITX-6412A and is the answer not in the manual?

Questions and answers

Summary of Contents for GIGAIPC mITX-6412A

  • Page 1: Mitx-6412A Mini-Itx Motherboard

    (MEHLJAI-SI) mITX-6412A Mini-ITX Motherboard User’s Manual 1st Ed www.gigaipc.com...
  • Page 2: Copyright Notice

    While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein.
  • Page 3: Acknowledgement

    Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com...
  • Page 4: Packing List

    Before setting up your product, please make sure the following items have been shipped: Item Quantity mITX-6412A MB SATA power cable I/O Shield If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5: About This Document

    (if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com...
  • Page 6: Safety Precautions

    Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com...
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
  • Page 8: Fcc Statement

    Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com...
  • Page 9: China Rohs Requirements (Cn)

    China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○...
  • Page 10: China Rohs Requirement (En)

    China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
  • Page 11: Table Of Contents

    Table Contents mITX-6412A Mini-ITX Motherboard User’s Manual 1st Ed Copyright Notice ................2 Acknowledgement ............... 3 Packing List ................... 4 About this Document ..............5 Safety Precautions ............... 6 FCC Statement ................8 China RoHS Requirements (CN) ............ 9 China RoHS Requirement (EN) ........... 10 Chapter 1 - Product Specifications Specifications ...............
  • Page 12 2.2.24 M2M (M.2 Slot, 2280 M-Key) ........45 2.2.25 M2E (M.2 Slot, 2230 E-Key) .......... 46 2.2.26 BATTERY (Battery Connector) ........47 2.2.27 BKL_CN (Backlight Control header) ......48 2.2.28 LSW (LVDS resolution jumper) ........49 2.2.29 LVDS (LVDS Connector) ..........50 www.gigaipc.com...
  • Page 13 AMI Graphic Output Protocol Policy ......66 3.3.8 Network Stack Configuration ........67 3.3.9 Offboard SATA Controller Configuration ...... 68 3.3.10 Digital IO Port Configuration ........69 Chipset ................70 Security ................. 72 Boot ................75 Save & Exit ..............76 www.gigaipc.com...
  • Page 14: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com...
  • Page 15 31.6 170.00 11.05 33.02 132.08 0.00 12.0 38.27 73.62 102.77 123.71 143.6 170.00 31.03 154.93 35.43 www.gigaipc.com...
  • Page 16: Specifications

    Specifications Motherboard mITX-6412A (MEHLJAI-SI) Mini-ITX Form Factor 170W x 170D (mm) Intel® Celeron® J6412 Processor 10nm, 4 cores, 4 threads, up to 2.60 GHz TDP 10W Socket 1 x FCBGA1493 2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB Memory...
  • Page 17 Motherboard mITX-6412A (MEHLJAI-SI) 1 x 4-pin ATX main power connector 3 x SATA power connectors 1 x CPU fan header 1 x System fan header 1 x Front panel header 1 x Front panel audio header 1 x 2W Speaker out header 4 x USB 2.0 headers...
  • Page 18: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com...
  • Page 19: Jumpers And Connectors

    Jumpers and Connectors 30 31 www.gigaipc.com...
  • Page 20 F_USB2_2 16 SATA_LED SATA LED for SATA1~4 port SATAPWR, SATA Power Connector SATAPWR1, SATAPWR2 SATA0, SATA1, SATA 6Gb/s connector SATA2, SATA3, SATA0 : support SATA DOM with pin 8 for 5V. SATA4 19 CASE_OPEN chassis open intrusion alert header www.gigaipc.com...
  • Page 21 31 LSW LVDS resolution jumper 32 LVDS LVDS Connector 33 EDP Embedded Display Port connector 34 ATX_CTL ATX Control header JCOM1, RI# pin RI#/5V/12V Select jumper for COM1 & JCOM2 COM2 port SODIMMA, 2 x DDR4 SO-DIMM Sockets SODIMMB www.gigaipc.com...
  • Page 22: Io Connector Information

    4 HDMI HDMI Connector Serial port connector 5 COM2 (RS-232/422/485 & RI/5V/12V) USB 2.0 Connector USB_LAN1 GbE LAN port USB 3.2 Gen 1 Connector USB31_LAN2 GbE LAN port 10 MIC_IN Mic in port (Pink) 11 LINE_OUT Line Out port (Green) www.gigaipc.com...
  • Page 23: Dc_In1 (Dc In Jack Connector)

    2.2.2 DC_IN1 (DC In Jack connector) DC In Jack connector Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com...
  • Page 24: Dc_In2 (Atx 2X2 Pin Power Connector)

    2.2.3 DC_IN2 (ATX 2x2 Pin Power Connector) Pin 1 Power Connector Connector PN Vendor 740-81-04TW56 PINREX Connector type 2x2pin connector, pitch 4.2mm Pin No. Definition DC IN DC IN www.gigaipc.com...
  • Page 25: Vga (Vga Port)

    2.2.4 VGA (VGA Port) D-sub Connector Connector PN Vendor DZ11AA1-H5A7-4F FOXCONN D11015S021126N FENYING Pin No. Definition Pin No. Definition Green Blue DDCSDA HSYNC VSYNC DDCSCL www.gigaipc.com...
  • Page 26: Com1

    2.2.5 COM1 (Serial port connector (RS-232/422/485 & RI/5V/12V)) Serial Port Connector Connector PN Vendor DM10151-N5W3-4F FOXCONN RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com...
  • Page 27: Hdmi (Hdmi Connector)

    2.2.6 HDMI (HDMI Connector) HDMI Connector Connector PN Vendor ABA-HDM-020-P05_A LOTES Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com...
  • Page 28: Com2

    2.2.7 COM2 (Serial port connector (RS-232/422/485 & RI/5V/12V)) Serial Port Connector Connector PN Vendor DM10151-N5W3-4F FOXCONN RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com...
  • Page 29: Usb_Lan1 (Usb 2.0 Connector (Bottom) + Gbe Lan Port (Top))

    USB 2.0 connector LAN Connector USB Connector Pin No. Definition Pin No. Definition Pin No. Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate www.gigaipc.com...
  • Page 30: Lan Port (Top))

    Pin No. Definition Pin No. Definition Definition Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- State Description USB3_RX1n USB3_RX2n Orange On 1Gbps data rate USB3_RX1p USB3_RX2p Green On 100Mbps data rate USB3_TX1n USB3_TX2n 10Mbps data rate USB3_TX1p USB3_TX2p www.gigaipc.com...
  • Page 31: Cpu_Fan (Cpu Fan Connector)

    2.2.10 CPU_FAN (CPU Fan Connector) Pin 1 CPU Fan Connector Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Connector type 1x4pin connector, pitch 2.54mm Pin No. Definition Detect Speed Control www.gigaipc.com...
  • Page 32: Sys_Fan (System Fan Connector)

    2.2.11 SYS_FAN (System Fan Connector) Pin 1 System Fan Connector Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Connector type 1x4pin connector, pitch 2.54mm Pin No. Definition www.gigaipc.com...
  • Page 33: F_Usb2_1, F_Usb2_2 (Usb 2.0 Header)

    2.2.12 F_USB2_1, F_USB2_2 (USB 2.0 header) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type Pin No. Definition 2x5pin connector, pitch 2.54mm No Pin www.gigaipc.com...
  • Page 34: Sata_Led (Sata Led For Sata1~4 Port)

    2.2.13 SATA_LED (SATA LED for SATA1~4 port) Pin 1 SATA LED select jumper Connector PN Vendor 222-97-04GBE1 PINREX Connector type 2x4pin connector, pitch 2.00mm Pin No. Definition SATA1 LED 3.3V SATA2 LED 3.3V SATA3 LED 3.3V SATA4 LED 3.3V www.gigaipc.com...
  • Page 35: Satapwr, Satapwr1, Satapwr2 (Sata Power Connector)

    2.2.14 SATAPWR, SATAPWR1, SATAPWR2 (SATA Power Connector) Pin 1 SATA Power Connector Connector PN Vendor 743-91-045W00 PINREX Connector type 1x4pin connector, pitch 2.54mm Pin No. Definition www.gigaipc.com...
  • Page 36 2.2.15 SATA0, SATA1, SATA2, SATA3, SATA4, SATA5 (SATA 6Gb/s Connector) SATA 6Gb/s Connector Pin No. Definition SATA 0 SATA 3 SATA 1 SATA 4 SATA 2 NOTE : SATA0 port supports SATA DOM with pin 8 for 5V. www.gigaipc.com...
  • Page 37: Case_Open (Chassis Open Intrusion Alert Header)

    2.2.16 CASE_OPEN (chassis open intrusion alert header) chassis open intrusion alert header Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Connector type 1x2pin header, pitch 1.25mm Pin No. Definition Detect www.gigaipc.com...
  • Page 38: At_Cn (At/Atx Mode Select Jumper)

    AT/ATX mode select jumper Connector PN Vendor 220-96-03GB01 PINREX 220-96-03GB001K PINREX PH03N2-7BAN000 HORNGTONG Connector type Pin No. Definition 1x3pin header, pitch 2.0mm AT MODE Detect ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com...
  • Page 39: Sys_Panel (System Panel Header)

    2.2.18 SYS_PANEL (System Panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition HD-P MPD-P HD-N MPD-N POWER-ON Reset Reserved www.gigaipc.com...
  • Page 40: Gpio_Cnt (General Purpose Input/Out Header)

    2.2.19 GPIO_CNT (General purpose input/out header) Pin 1 GPIO Connector Pin No. Definition SMBus DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 A2004WV-2X06P46 JOINT-TECH GPIO-output_2 GPIO-input_2 Connector type GPIO-output_3 2x6pin header, pitch 2.0mm GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock www.gigaipc.com...
  • Page 41: Com3, Com4, Com5, Com6 (Serial Port Header (Rs-232))

    2.2.20 COM3, COM4, COM5, COM6 (Serial port header (RS-232)) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Pin No. Definition No connect www.gigaipc.com...
  • Page 42: Pciex1 (1 X Pcie X1 (Gen 3X1) Slot)

    2.2.21 PCIEX1 (1 x PCIe x1 (Gen 3x1) Slot) PCIEX1 connector www.gigaipc.com...
  • Page 43: Spkr (Speaker Out Connector)

    2.2.22 SPKR (Speaker Out Connector) Pin 1 Speaker Out Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition SPEAKER L+ SPEAKER L- SPEAKER R- SPEAKER R+ www.gigaipc.com...
  • Page 44: Fp_Audio (Front Panel Audio Header)

    2.2.23 FP_AUDIO (Front Panel Audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Definition Pin Definition MIC-LEFT JACKSENCE DELTECT MIC-RIGHT DELTECT LINE-LEFT LINE-RIGHT www.gigaipc.com...
  • Page 45: M2M (M.2 Slot, 2280 M-Key)

    SATA TXn 3.3V SATA TXp PCI Reset PCIE Clock Request SSD LED SATA Clockn 3.3V SATA Clockp 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK 3.3V 3.3V 3.3V Connector PN Vendor 80159-8521 BELLWETHER 2E0BC21-S85BM-7H FOXCONN APCI0096-P002A LOTES www.gigaipc.com...
  • Page 46: M2E (M.2 Slot, 2230 E-Key)

    PCIE CLOCKn SUSCLK PCIE Clock Pin No. Definition Pin No. Definition PCIRST Request 3.3V PCIE wake up BT_Disable 3.3V WLAN_DISABLE 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 2E0BC21-S85BE-7H FOXCONN 80152-8521 BELLWETHER PCIE_TXp APCI0095-P002A LOTES PCIE_TXn www.gigaipc.com...
  • Page 47: Battery (Battery Connector)

    2.2.26 BATTERY (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com...
  • Page 48: Bkl_Cn (Backlight Control Header)

    2.2.27 BKL_CN (Backlight Control header) Pin 1 Backlight Control Connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Connector type 1x5pin header, pitch 2.0mm Pin No. Definition 12V (5V optional) Backlight enable www.gigaipc.com...
  • Page 49: Lsw (Lvds Resolution Jumper)

    1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com...
  • Page 50: Lvds (Lvds Connector)

    But below model no need to add. A0~A3 is odd channel 0~3, A4~A7 is ev en channel. Note: *The LVDS output connector of the CLK2+ CLK1+ unit is only intended to be connected to an CLK2- UL/IEC/EN approval equipment with fire CLK1- enclosure. www.gigaipc.com...
  • Page 51: Edp (Embedded Display Port Connector)

    Definition 3.3V TX3n TX3p AUXn Pin No. Definition Pin No. Definition AUXp Hot Plug Connector PN Vendor TX0n Detect 115B30-000040-G4-R STARCONN Backlight TX0p Enable Connector type 1x30pin header, pitch 0.5mm Backlight TX1n controll TX1p 3.3V TX2n 3.3V TX2p 3.3V www.gigaipc.com...
  • Page 52: Atx_Ctl (Atx Control Header)

    2.2.31 ATX_CTL (ATX Control header) Pin 1 ATX Control Header Connector PN Vendor 744-81-02TW10 PINREX Connector type 1x2pin header, pitch 2.54mm Pin No. Definition PSON# www.gigaipc.com...
  • Page 53: Jcom1, Jcom2 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 & Com2 Port)

    Pin 1 JCOM1, JCOM2 Connector PN Vendor Jumper Select 220-97-03GB01 PINREX PH06N53BAZ000 HORNGTONG 1-2 Close: JCOM2 Connector type 5V (Power COM) JCOM1 2x3pin header, pitch 2.0mm 3-4 Close: JCOM2 RI (Stand COM) JCOM1 5-6 Close: JCOM2 12V (Power COM) JCOM1 www.gigaipc.com...
  • Page 54: Sodimma, Sodimmb (2 X Ddr4 So-Dimm Sockets)

    2.2.33 SODIMMA, SODIMMB (2 x DDR4 SO-DIMM Sockets) www.gigaipc.com...
  • Page 55: Chapter 3 - Bios

    Chapter 3 Chapter 3 – BIOS www.gigaipc.com...
  • Page 56: Introduction

    Execute command or enter the submenu Increase the numeric value or make + changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...
  • Page 57: The Main Menu

    ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...
  • Page 58: Advanced

    Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...
  • Page 59: Tpm Configuration

    3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM (Default setting) TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB) www.gigaipc.com...
  • Page 60 Item Description Security Device Enabled : Enables TPM feature (Default setting) Support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
  • Page 61: It8786 Super Io Configuration

    Enabled : Enables allows you to configure the serial port settings Serial Port 5 Configuration Disabled : if Disabled, displays no configuration for the serial port Serial Port 6 Configuration Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...
  • Page 62: Hardware Monitor

    Enabled : Enables warning message Clear : Clear the chassis intrusion status record CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed Shows current CPU fan Speed SYS Fan Speed Shows current System fan Speed www.gigaipc.com...
  • Page 63: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...
  • Page 64: Cpu Configuration

    Enabled : Enables CPU C states function (Default setting) Disabled : Disables CPU C states function CPU will adjust frequency depends on it's loading. CPU P states Enabled : Enables CPU P states function (Default setting) Disabled : Disables CPU P states function www.gigaipc.com...
  • Page 65: Sata Configuration

    3.3.6 SATA Configuration Item Description SATA Mode Set SATA controller to AHCI mode Selection Serial ATA Port 0 shows HDD/SSD information of SATA 0 port M.2 Port shows M.2 SSD information www.gigaipc.com...
  • Page 66: Ami Graphic Output Protocol Policy

    3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor Output Select plugged on the motherboard. www.gigaipc.com...
  • Page 67: Network Stack Configuration

    When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com...
  • Page 68: Offboard Sata Controller Configuration

    3.3.9 Offboard SATA Controller Configuration Item Description PCIE SATA Controller 0 shows HDD/SSD information of SATA 1 ~ 4 port - SATA Port 1~4 www.gigaipc.com...
  • Page 69: Digital Io Port Configuration

    Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com...
  • Page 70: Chipset

    Disabled : Disables onboard LAN controller To choose whether if to use ATX PSU to boot up. ATX control Enabled : Enables if needed to use ATX PSU to boot up. Disabled : Disables ATX control function (Default setting) www.gigaipc.com...
  • Page 71 To modified the backlight brightness of the LVDS/EDP panel Brightness Level Option items : 10%, 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100% (Default Setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
  • Page 72: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 73 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 74 Yes : Agree to remove 'UEFI CA' 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to factory Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
  • Page 75: Boot

    Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com...
  • Page 76: Save & Exit

    Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
