2.2.28 COM1 (Serial port (RS-232/422/485 & RI/5V/12V))
34
Serial Port Connector
Pin
RS-232
No.
1
DCD
2
RXD
3
TXD
4
DTR
5
6
DSR
7
RTS
8
CTS
9
49
www.gigaipc.com
1
6
RS-422
Full Duplex
Half Duplex
TXD-
TXD+
RXD+
RXD-
GND
–
–
–
RI
–
Connector PN
DM10151-N5W3-4F
RS-485
D-
D+
–
–
–
–
–
–
Vendor
FOXCONN
