GIGAIPC mITX-H310A User Manual page 20

No Code
12 DC_IN2
13 COM4
14 COM3
15 M2E
16 SYS_FAN
17 GPIO_CNT
18 TPM
19 SATA_PWR1
20 SATA1
21 SATA2
22 ATX_CTL
23 JCOM16
24 CLR_CMOS
25 JRS21-24
26 COM2
27 SYS_PANEL
28 FUSB2_1
29 FUSB2_2
30 CPU_FAN
31 SODIMM1
32 SODIMM2
33 DC_IN1
ATX 2x2 pin power connector
Serial port header (RS-232)
Serial port header (RS-232)
1 x M.2 2230 E-Key slot
System fan connector
General Purpose input/output header
TPM connector
SATA 6Gb/s power connector
SATA 6Gb/s connector
SATA 6Gb/s connector
ATX Control header
RI pin RI/5V/12V select jumper for COM2
port
Clear CMOS jumper
RS-232/422/485 select jumper for COM2
port
Serial port header (RS-232/422/485 &
RI/5V/12V)
Front panel header
USB 2.0 header
USB 2.0 header
CPU fan connector
DDR4 SO-DIMM slot#1
DDR4 SO-DIMM slot#2
DC In Jack
Description
