3.3.2.5 Handlebars

The pedelec is steered using the handlebars. The
handlebars are used to support the upper body
and is the mount for most controls and displays
(see Section 3.4.1).
3
Figure 6: Handlebar dimensions
The main dimensions of handlebars are:
1 Rise (height)
2 Width
3 Backsweep
MY22Z01 - 12_1.0_25.07.2022
2
1

3.3.2.6 Fork

The stem and handlebars are attached to the top
end of the fork steerer. The axle is fastened to the
fork ends. The wheel is fastened to the axle.
2
3
Figure 7: Overview of fork
1 Fork steerer
2 Side reflectors (optional)
3 Fork end
4 Fork leg
Description
1
4
