REMOVING PANS AND DIVIDERS (FOR CLEANING)

Removing Pans and Dividers (for Cleaning)
Note: Make certain that unit has been turned off and
allowed to cool before accessing.
1. Remove 1/3rd-Size and Full Size Pans.
2. Remove pan dividers.
1. Remove 1/3rd-Size, Full
Size and/or Drip Pans
Pan (1/3rd
Size) Typ.
Pan (Full
Size) Typ.
3. Perform cleaning
service on pan
warmer shield
3. Perform cleaning service on pan warmer shield.
4. Replace pan dividers and pans in reverse order they
were removed.
Note: See cleaning schedule for specifics on
method and frequency of cleaning.
Note: Illustration Shown May Not
Exactly Reflect Every Feature or
Option of Your Particular Case.
15
2. Remove pan
dividers
4. Replace pan
dividers and pans in
reverse order they
were removed
