The F/W SCSI connector is part number 1252–4426, a 68–pin high–density D–sub right–angle
connector.
Table 9–2. RS–232 Connectors (2)
Pin
1 FW_SD12+
2 FW_SD13+
3 FW_SD14+
4 FW_SD15+
5 FW_SP1+
6 Gnd
7 FW_SD0+
8 FW_SD1+
9 FW_SD2+
10 FW_SD3+
11 FW_SD4+
12 FW_SD5+
13 FW_SD6+
14 FW_SD7+
15 FW_SP0+
16 FW_DIFFSENS
17 FW_TERM POWER
18 FW_TERM POWER
19 not connected
20 FW_SATN+
21 Gnd
22 FW_SBSY+
23 FW_SACK+
24 FW_SRST+
25 FW_SMSG+
26 FW_SSEL+
27 FW_SCD+
28 FW_SREQ+
29 FW_SIO+
30 Gnd
31 FW_SD8+
32 FW_SD9+
33 FW_SD10+
34 FW_SD11+
Signal Name Pin Signal Name
35 FW_SD12–
36 FW_SD13–
37 FW_SD14–
38 FW_SD15–
39 FW_SP1–
40 Gnd
41 FW_SD0–
42 FW_SD1–
43 FW_SD2–
44 FW_SD3–
45 FW_SD4–
46 FW_SD5–
47 FW_SD6–
48 FW_SD7–
49 FW_SP0–
50 Gnd
51 FW_TERM POWER
52 FW_TERM POWER
53 not connected
54 FW_SATN–
55 Gnd
56 FW_SBSY–
57 FW_SACK–
58 FW_SRST–
59 FW_SMSG–
60 FW_SSEL–
61 FW_SCD–
62 FW_SREQ–
63 FW_SIO–
64 Gnd
65 FW_SD8–
66 FW_SD9–
67 FW_SD10–
68 FW_SD11–
