Built–In Interfaces
System Unit Interfaces
The system board's built–in interfaces have ports on the workstation rear panel.
Audio Interfaces
The J Class workstations have audio input and output capability through external input and output
connectors on the rear panel and through an internal speaker. The rear panel contains the Audio IN (Stereo
line–in) and Mic (Mic–in), and Audio OUT (Stereo line–out) and Headphones (Headphone–out)
connectors.
The audio connectors are standard stereo audio mini–jacks. Hewlett–Packard recommends using
gold–plated plugs available through audio retailers for best quality recording and playback through the
external connectors. The following is a summary of the workstation audio features:
Audio Features Programmable sample rates:
8kHz, 16kHz, 32kHz, 48kHz, 11.025kHz, 22.05kHz, and 44.1kHz.
Programmable output attenuation:
0 to –96dB in –1.5dB steps
Programmable input gain:
0 to 22.5dB in 1.5dB steps.
Input monitoring:
16–bit linear, 8–bit u–law, or A–law coding
Audio Inputs Line–in
Mono microphone compatible with 1.5V phantom supply
(bias voltage supplied by the system)
CD–ROM audio (if internal CD–ROM is installed)
Audio Outputs Line–out
Headphone
Built–in mono speaker
Audio CODEC Crystal CS4215
Table 1–2 summarizes the
audio electrical specifications for this workstation.
