Input Power
Input Voltage (115V range)
Input Current (115V range)
Input Voltage (230V range)
Input Current (230V range)
Line Frequency
Electrical Information
Output Connectors
There are three panel mount output connectors used; P1, P2, and P3.
P1 housing:
P2, P3 housing:
P1, P2, and P3 contacts:
.
Table 7–2 Power Supply Input Specifications
.
Table 7–3 Power Supply Demand
System Board (Dual Processor)
LAN
SCSI Adapter
Multi Function I/O
RS232 & Centronics
Multimedia
HP HIL
Drives – 2 x 2 GB FW
Drive – CD–ROM
Drive – Floppy or DDS
Fans
Graphics and keyboard Interface
EISA
Total Power
Molex 15–06–0180 (18 position)
Molex 15–06–0240 (24 position)
Molex 39–00–0078, 16AWG or
Molex 39–00–0039, 18–24AWG
664W
88 to 138Vac RMS
11.5A RMS max.
193 to 269Vac RMS
6A RMS max.
45 to 66 Hz
203.0 W
5.0
3.0
2.5
1.5
4.9
10.0
36.8
6.0
6.0
7.2
8.0
110.2
407.6 W
