Additional Resources; Conventions; Typographical - Xilinx Virtex-6 FPGA ML605 Embedded Kit Getting Started

Preface: About This Guide
•
•
•
•
This guide provides information on PCB design for Virtex-6 devices, with a focus on
strategies for making design decisions at the PCB and interface level.

Additional Resources

To find additional documentation, see the Xilinx website at:
To search the Answer Database of silicon, software, and IP questions and answers, or to
create a technical support WebCase, see the Xilinx website at:

Conventions

This document uses the following conventions. An example illustrates each convention.

Typographical

The following typographical conventions are used in this document:
6
Virtex-6 FPGA DSP48E1 Slice User Guide
This guide describes the DSP48E1 slice in Virtex-6 FPGAs and includes configuration
examples.
Virtex-6 FPGA Embedded Tri-Mode Ethernet MAC User Guide
This guide describes the dedicated tri-mode Ethernet media access controller
(TEMAC) available in all the Virtex-6 FPGAs except the XC6VLX760.
Virtex-6 FPGA System Monitor User Guide
This guide describes the System Monitor functionality.
Virtex-6 FPGA PCB Designer's Guide
http://www.xilinx.com/support/documentation/index.htm.
http://www.xilinx.com/support.
Convention
Messages, prompts, and
program files that the system
Courier font
displays
Literal commands that you enter
Courier bold
in a syntactical statement
Commands that you select from
a menu
Helvetica bold
Keyboard shortcuts
www.xilinx.com
Meaning or Use Example
speed grade: - 100
ngdbuild design_name
File → Open
Ctrl+C
ML605 Getting Started Guide
UG730 (v1.1) June 14, 2010
