Performance Monitor Application: Start Data Traffic
A. Click on Start Test to begin XAUI data transfer.
B. Click on Start Test to begin Raw data transfer.
Congratulations! The Virtex-6 FPGA Connectivity Kit is now set up. The pre-built connectivity targeted reference design demonstration has
been tested, using the built-in block for PCI Express (x4 PCI Express Gen2 Endpoint), XAUI LogiCORE IP, a Virtual FIFO memory controller
designed to interface to the on-board DDR3 memory, and Northwest Logic's high performance DMA controller for PCI Express.
Next, please refer the Getting Started Guide included in this kit. The guide provides further instructions on running the demo, evaluating and
modifying the design files – Hardware RTL design and Software Device Driver. For updated information on this Virtex-6 FPGA Connectivity
Kit, please visit www.xilinx.com/v6connkit.
Support Information
To download Design Tools, generate license or get the latest tool updates go to www.xilinx.com/support/download.
For Technical Support, go to www.xilinx.com/support. On this site you can:
• Subscribe to Alerts on Product Technical Documentation updates
• Choose instructor-led classes and recorded e-learning options under Training
• Collaborate with the Xilinx User Community on the Forums
• Quickly scan titles of Answers Database categories through the Answer Browser
• Submit cases and report bugs online 24 hours a day through webCase
• Initiate and manage return of hardware and software products through the RMA Portal
Corporate Headquarters Europe
Xilinx, Inc. Xilinx Europe
2100 Logic Drive One Logic Drive
San Jose, CA 95124 Citywest Business Campus
USA Saggart, County Dublin
Tel: 408-559-7778 Ireland
www.xilinx.com Tel: +353-1-464-0311
www.xilinx.com
© Copyright 2010 Xilinx, Inc. XILINX, the Xilinx logo, Virtex, Spartan, ISE and other designated brands included herein are trademarks of Xilinx in the United States and other
countries. All other trademarks are the property of their respective owners. Printed in the U.S.A.
VIRTEX-6 FPGA CONNECTIVITY KIT
STE P 10I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I
Performance Monitor Application: Verify Data Throughput
and Error Free Operation
A. Confirm PCIe Throughput.
B. Confirm DMA Channel throughput for the XAUI path.
C. Confirm DMA Channel throughput for the Raw Data path.
D. Confirm Error Free operation - no Buffer Descriptor Errors.
