Data Plate - Ariston NIMBUS HYBRID MODULE UNIVERSAL NET Manual

Internal unit data plate
1
3
12
9
10 11
2
Legend:
1. Brand
2. Manufacturer
3. Appliance model - Serial num-
ber
4. Commercial reference
5. Certifi cation number
9. Electrical data
11. Maximum heating pressure
12. Nominal power of heating
elements
Refrigerant data
Refrigerant type
Load of the refrigerant
[g]
GWP
CO Equivalent (t)
2
NOTE:
The external unit belonging to the purchased product is supplied with the energy label relative to a specifi c confi guration, in accord-
ance with that stated in Regulation (EU) No. 811/2013; if your chosen confi guration does not match the one on the label, you can fi nd
the correct label on the website ariston.com or by contacting the customer service at +39 0732 633528.
4
5
MAX MIN
40 M EXT 50 M EXT
R410A R410A
1880 1880
2088 2088
3,9 3,9
External unit data plate
2
3 4
7
11
14
16 17
19
Legend:
1. Homologation
2. Certifi cation
3. Model
4 Performance Ratings heating circuit
5 Cooling date
6 Performance Ratings cooling circuit
7 Type of oil in the refrigerant circuit
8 Refrigerant type - load of the refrigerant
9 GWP
10 CO Equivalent (t)
2
11 Electrical data
12 Electrical protection
13 Maximum electric power
14. Maximum pressure refrigerant circuit
15. Minimum pressure refrigerant circuit
16 Plant of manufacturing
17 Protection rating
18 Certifi cate
19 Contact address
70 M EXT 70 M-T EXT
R410A R410A
2770 2770
2088 2088
5,8 5,8
1
5 6
8 9 10
12 13
15
18
90 M-T EXT 110 M-T EXT
R410A R410A
3900 3900
2088 2088
8,1
/ 93
8,1
