PDLN4100 and PDLN4500
The Networx PDL Series locks include several lock types, but this manual will focus on two: The
PDLN4100 and PDLN4500. The PDLN4100 is a cylindrical lock, and the PDLN4500 is a mortise-
based lock, for extra security. Both allow use of "Residency" and "Privacy" features, and can be pro-
grammed either way to suit the installation requirements.
Both locks feature an HID compatible ProxCard
adjusts for Daylight Saving Time and allows for automated programming of events. Up to 5000 unique
User Codes can be added to the lock, from 3-6 digits in length.
PDLN4100
"Residency" and "Privacy" Features
The "Residency" feature is specially designed to prevent unintentional lock-out (typically used in retire-
ment homes and college dormitories), and the "Privacy" feature is designed to deny access to other
users after an individual enters (typically used for rooms needing privacy from others such as bath-
rooms, dorms and meeting rooms). See pages 18-19 for more information about "Residency" and
"Privacy" Features.
Wireless Networx, DL-Windows and Keypad Programming
The Trilogy Networx
grammed either at the keypad or through its Networx-radio link to a DL-Windows equipped computer.
For example, Audit Log Data may be transmitted through the radio link back to the DL-Windows com-
puter.
If your Networx wireless network is not yet set up, you can add Users and program other features using
the lock keypad as a temporary convenience to allow the lock to be put into use before installing the
wireless network. However, be aware that all programming added using the keypad cannot be retrieved
into DL-Windows, so if you decide to start programming using the lock keypad, we recommend you
keep hardcopy records (in a secure location) of all Users, User Codes, and any proximity credentials
PDLN4500
that may have been programmed. Keeping these hardcopy records will save time because after the
wireless network is set up, all programming added via the lock keypad can easily be re-added to DL-
Windows and downloaded back to the lock(s)*.
These instructions include manual keypad programming. For DL-Windows user instructions, see the DL
-Windows User's Guide (OI382); for configuring your wireless system, see the DL-Windows for Networx
User's Guide (OI383).
Note: ProxCard
*
For installations without a network, we recommend enabling Function 94 ("Disable Radio").
Lock Features ........................................................................ 3
Supported Products ........................................................ 4 - 5
Lock Design Overview .......................................................... 6
Terminology Used in this Manual ................................. 7 - 8
Programming Levels ............................................................ 9
Conventions Used in this Manual ..................................... 10
LED and Sounder Indicators ............................................. 10
Emergency Commands .............................................. 11 - 12
Wireless Remote Releases ................................................ 13
Wiring and Power Up .......................................................... 14
Quick Start .................................................................... 15 - 17
The word "credential" used throughout this manual is a generic word intended to describe a User Code, a proximity card, proximity keyfob
®
(such as a ProxKey keyfob), a hardwired Remote Input momentary contact, a Wireless Remote Release, or any future device or design
that allows the lock to unlock, allowing passage through the door. Trilogy
®
ProxKey are trademarks of the HID
