Wireless Trilogy
Networx
PL6500 & ETPLN
™
345 Bayview Avenue
Programming Instructions
Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
(Note: Technical Service is for locksmiths and alarm professionals only)
© ALARM LOCK 2012
WI1844A 04/12
Publicly traded on NASDAQ
Symbol: NSSC
PL6500 & ETPLN
H I D
HID CORPORATION
H I D
DL-WINDOWS
PROGRAMMING SOFTWARE
®
PROXCARD
®
PROXKEY
KEYFOB
®
AL-PRE PROXCARD
READER / ENROLLER
PL Wireless Trilogy Series
Network Access Control System
with ProxCard
Access
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL6500 and is the answer not in the manual?

Questions and answers

Related Manuals for Alarm Lock PL6500

Summary of Contents for Alarm Lock PL6500

  • Page 1 Wireless Trilogy Networx PL6500 & ETPLN ™ 345 Bayview Avenue Programming Instructions Amityville, New York 11701 For Sales and Repairs 1-800-ALA-LOCK For Technical Service 1-800-645-9440 (Note: Technical Service is for locksmiths and alarm professionals only) © ALARM LOCK 2012 WI1844A 04/12...

  • Page 2: Table Of Contents

    ECURITY PL6500 & ETPLN The PL6500 and ETPLN security locks are designed to allow all features to be programmed through its radio link from a DL-Windows-equipped computer. In addition, Audit Log Data may be transmitted through the radio link back to the DL-Windows computer.

  • Page 3: Wireless Pl Series Lock Features

    • Users Assignable to 4 Groups (see page 7 for definition of "Group") Computer Programming • Full programming allowed from a PC using Alarm Lock's DL-Windows Software. For a description of all features, see the DL-Windows User's Guide, OI237 or the Wireless Network Setup & DL-Windows Configu-...

  • Page 4: Supported Products

    (either wirelessly or wired) to a computer network such as a LAN or corporate Intranet. A Windows PC connected to this network can control and program all PL6500 / ETPLN locks by the use of the DL-Window software (see OI237 and OI352). With access rights to the software, one computer--or several--can control the software and consequently can control the devices in the system.

  • Page 5: Lock Design Overview

    PL6500 / ETPLN lock should the future need arise. Once you unpack your PL6500 / ETPLN from the box, there is a specific procedure that must be followed for proper operation (detailed in "First Time Power Up" on page 8). Turn the page and learn about the special terminology used with your lock.

  • Page 6: Terminology Used In This Manual

    Lock Program to its programming memory, that means you can have up to allow entry (to allow the PL6500 / ETPLN to unlock). 5000 Users each in possession of a proximity card or The proximity card entries are a part of the Lock Pro- fob.
  • Page 7 Number defines the Programming Level for that User. and accountability of a guard's movement by logging Because the PL6500 / ETPLN does not contain a key- the location with a time and date stamp in the Event pad, all User Numbers are "Basic Users", meaning each Log ("Audit Trail").

  • Page 8: Wiring

    For models with a replacable battery pack, use four (4) C-size 1.5 volt alkaline batteries. For models with a sealed battery pack, contact your Alarm Lock dealer for a replacement battery pack. Always replace weak batteries as soon as possible.

  • Page 9: Erase All Programming

    Test by simply presenting a valid proximity card or fob to the reader in front of the lock. VALID CARD - Green LED flashes, the sounder beeps several times and the PL6500/ETPLN unlocks. INVALID CARD - Red LED flashes several times and the sounder beeps several times.

  • Page 10: Dl-Windows Programmable Features Screen

    Group 2 Enables and 3 Disables Passage Mode grammed lock. A Group 2 User will put the PL6500/ETPLN into pas- sage mode (lock is unlocked). A Group 3 User will take Pass Time In Seconds the PL6500/ETPLN out of passage.
  • Page 11 Remote Input is disabled. Provides an alert supply. If this option is selected, the relay remains acti- that an unsuccessful access has been attempted via the vated as long as the PL6500/ETPLN is unlocked. This Remote Input. feature supersedes all other relay options.
  • Page 12 MUST be provided from an external power supply. The "Remote Input" wires are two white wires located inside the rear housing. When these two white Remote Input wires are momentarily shorted, the PL6500/ ETPLN unlocks. These Remote Input wires are enabled at the factory and are ready for use.

  • Page 13: User Card Record Sheet

    User Card Record Sheet Page # ______ NAME OF DOOR: DEPARTMENT: EMBOSSED NUMBER ON CARD USER NAME (LAST, FIRST) DATE ACTIVATED COMMENTS...

  • Page 14: Glossary

    DL-Windows. through the door). DEFAULT = The original settings that were set at the INTERNAL RELAY FUNCTIONS = The PL6500/ factory; in other words, it is the lock's original factory ETPLN internal relay can be programmed (via DL- condition when the lock was first taken out of its Windows only) for one or more functions.
  • Page 15 NOTES...

  • Page 16: Limited Warranty

    In no event shall ALARM LOCK be liable for an amount in excess of ALARM LOCK's original selling price of the prod- uct, for any loss or damage, whether direct, indirect, incidental, consequential, or otherwise arising out of any failure of the product.
