Save & Exit Setup; Exit Without Saving - DFI 586ITX User Manual

Hard Disk Low Level Format Utility
DRIVE: C CYLINDER: 0
SIZE
Primary Master:
853
Primary Slave:
Secondary Master:
Secondary Slave:
Up/Down-Select item
Copyright (C) Award Software, Inc. 1992-94 All Rights Reserved
Warning:
Do not use this HDD Low Level Format feature for IDE hard drives.
They already have been low-level formatted at the factory. Do a high-
level format only for these drives. Refer to the manual that comes with
your operating system.
Save & Exit Setup
When all the changes have been made, highlight " Save & Exit Setup"
and press <Enter>. The message below will appear:
Save to CMOS and Exit (Y/N)? N
Type " Y" and press <Enter>. The modifications you have made will be
written into the CMOS memory, and the system will reboot. You will
once again see the initial diagnostics on the screen. If you wish to
make additional changes to the setup, press <Ctrl> <Alt> <Esc> simul-
taneously or <Del> after memory testing is done.

Exit Without Saving

When you do not want to save the changes you have made, highlight " Exit
Without Saving" and press <Enter>. The message below will appear:
Quit Without Saving (Y/N)? N
58
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
SELECT DRIVE
BAD TRACK LIST
PREFORMED
Current select drive is : C
HEAD: 0
LANDZ
CYLS HEAD RECOMP
1654 16 65536
0 0 0 0
0 0 0 0
0 0 0 0
ENTER-Accept
No. CYLS HEAD
SECTOR
MODE
1653 63
AUTO
0 0
AUTO
0 0 AUTO
0 0 AUTO
ESC-Exit/Abort
