Enabled Optional shadow is enabled.
Disabled Optional shadow is disabled.

Chipset Features Setup

This section gives you instructions on how to configure the system
based on the specific features of the chipset. This chipset manages bus
speeds and access to system memory resources. It also coordinates
communications between the conventional ISA bus and the PCI bus.
These items should not be altered unless necessary. Depending on
your add-in boards, you may not or should not enable some of those
features. The default settings have been chosen because they provide
the best operating conditions for your system. The only time you might
consider making any changes would be if you discovered some incom-
patibility or that data was being lost while using your system.
Auto Configuration
DRAM Timing
DRAM Leadoff Timing
DRAM Read Burst (EDO/FP)
DRAM Write Burst Timing
Fast EDO Lead Off
Refresh RAS# Assertion
Fast RAS To CAS Delay
DRAM Page Idle Timer
DRAM Enhanced Paging
Fast MA to RAS# Delay
SDRAM (CAS Lat/RAS-to-CAS)
System BIOS Cacheable
Video BIOS Cacheable
8 Bit I/O Recovery Time
16 Bit I/O Recovery Time
Memory Hole At 15M-16M
Extented CPU-PIIX4 PHLDA#
Host-to-PCI Bridge Retry
PCI Concurrency

Power Management Setup

Power Management Setup allows you to configure your system to most
effectively save energy. If you like to use the soft power down feature of
Windows 95, you must enable the Power Management below. Select
Min. Power, Max. Power or User Defined. Either one can be used as
long as it is NOT disabled.
44
ROM PCI/ISA BIOS
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Mem. Drive Str. (MA/RAS)
: Enabled
: Normal
: 10/6/3
: x444
: x333
: DIsabled
: 5 Clks
: 3
: 4 Clks
: Enabled
: 2 Clks
: 3/3
: Disabled
: Disabled
↑ ↓ → ←
ESC : Quit
: 4
F1 : Help PU/PD/+/-
: 2
: Disabled (Shift) F2
F5 : Old Values
: Disabled
F6 : Load Fail-Safe Settings
: Disabled
F7 : Load Optimal Settings
: Enabled
: Auto
: Select Item
: Modify
: Color
