Memory Size SIMM1
96MB 4MBx32
96MB 8MBx32
128MB 16MBx32
128MB
128MB 8MBx32
136MB 1MBx32
136MB 16MBx32
144MB 2MBx32
144MB 16MBx32
160MB 4MBx32
160MB 16MBx32
192MB 8MBx32
192MB 16MBx32
256MB 16MBx32
Installing a SIM Module
A SIM module simply snaps into a socket on the system board. Pin 1 of
the SIM module must correspond with Pin 1 of the socket.
1. Position the SIMM above the socket with the " notch" in the module
aligned with the " key" on the socket.
2. Seat the module at a 45° angle into the bank. Make sure it is com-
pletely seated. Tilt the module upright until it locks in place in the
socket.
Bank 0
SIMM2
4MBx32
8MBx32
16MBx32
— —
8MBx32
1MBx32
16MBx32
2MBx32
16MBx32
4MBx32
16MBx32
8MBx32
16MBx32
16MBx32
notch
key
Bank 1
SIMM3 SIMM4
8MBx32
8MBx32
4MBx32
4MBx32
—
—
16MBx32
16MBx32
8MBx32
8MBx32
16MBx32
16MBx32
1MBx32
1MBx32
16MBx32
16MBx32
2MBx32
2MBx32
16MBx32
16MBx32
4MBx32
4MBx32
16MBx32
16MBx32
8MBx32
8MBx32
16MBx32
16MBx32
