Summary of Contents for DFI 586ITX

  • Page 1 586ITX Rev . A + System Board User’ s Manual - 33370410 -...
  • Page 2 FCC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction ............5 Features and Specifications ..........6 Package Checklist .............. 8 Chapter 2: Hardware Installation ..........9 Preparing the Area.............. 9 Handling the System Board ..........9 Installing the System Board ..........10 Board Layout ..............12 System Memory ..............
  • Page 4 Load Optimal Settings ........... 50 Integrated Peripherals ........... 51 Supervisor Password ............ 54 User Password ............54 IDE HDD Auto Detection ..........55 HDD Low Level Format ..........57 Save & Exit Setup ............58 Exit Without Saving ............58 System Error Report ............

  • Page 5: Chapter 1: Introduction

    Chapter 1 Introduction The 586ITX, equipped with a 321-pin Zero Insertion Force (ZIF) CPU ® socket, is a Pentium processor-class system board supporting Intel ® Pentium processors running at 90MHz, 100MHz, 120MHz, 133MHz, 150MHz, 166MHz and 200MHz frequencies. The 586ITX also supports ®...

  • Page 6: Features And Specifications

    USB ports and one IrDA connector for wireless con- nectivity between your computer and peripheral devices. The 586ITX system board is designed to fit into an ATX form factor case. Using an ATX power supply, you can either shut down your com-...
  • Page 7 BIOS ® • Award BIOS, Windows 95 Plug and Play compatible • Flash EPROM for easy BIOS upgrades Energy Efficient Design • Supports ACPI specification and OS Directed Power Management • System power management supported • CPU stopped clock control •...

  • Page 8: Package Checklist

    • 1 shared PCI/ISA slot • 4 layers, ATX form factor • 30.48cm (12") x 23.04cm (9.07") Package Checklist The 586ITX package contains the following items: • The 586ITX system board • The 586ITX user’ s manual • One 40-pin IDE hard disk cable •...

  • Page 9: Chapter 2: Hardware Installation

    Chapter 2 Hardware Installation This chapter summarizes the steps to install the 586ITX system board into your system unit. It also includes a description of the area in which you must work and directions for memory installation. Before installing the system board, obtain the memory you plan to install. Refer to the System Memory section for the number and type of memory modules needed for the amount of memory you require.

  • Page 10: Installing The System Board

    ESD protection. Installing the System Board If you are installing the 586ITX system board, the following outlines the basic installation steps. Before installing the system board into your sys- tem unit, you should prepare the tools you will need.
  • Page 11 9-10 for proper handling tech- niques. 6. Insert the memory modules into the memory banks on the 586ITX. The quantity and location of the memory modules depends on the memory configuration and type of modules you intend to use.

  • Page 12: Board Layout

    Board Layout square denotes pin 1...
  • Page 13 Jumpers Refer to JP1, JP2, JP13, JP15 and JP20 pages 20-21 Intel and AMD processors page 26 JP7 - CMOS clear page 26 JP21 - Modem Ring-in select page 27 JP4, JP14, JP18, JP22 and JP23 Factory Testing Jumpers Sockets Refer to DM0 and DM1 - DIMM sockets pages 14-15...

  • Page 14: System Memory

    SIMM, which uses DRAM. Refer to page 12 for the locations of the DIM and SIM sockets. Important: DIM and SIM modules can not exist on the 586ITX system board at the same time. Use either SIMM or DIMM only. DIMM The two 168-pin DIMM (Dual In-line Memory Module) sockets use x64 EDO, FPM and SDRAM.

  • Page 15: Simm

    0 or Bank 1, but you must populate one bank first before going to the next bank. The 586ITX system board can support 8MB to 256MB of memory using 1MBx32, 2MBx32, 4MBx32, 8MBx32, or 16MBx32 72-pin SIMMs. The table on the next page shows the supported SIM modules and their...
  • Page 16 SIMMs Memory Size 1MBx32 2MBx32 4MBx32 16MB 8MBx32 32MB 16MBx32 64MB The table below summarizes the bank locations and modules needed for the corresponding memory sizes. Bank 0 Bank 1 SIMM1 SIMM2 SIMM3 SIMM4 Memory Size 1MBx32 1MBx32 — — —...
  • Page 17 Bank 0 Bank 1 SIMM2 Memory Size SIMM1 SIMM3 SIMM4 96MB 4MBx32 4MBx32 8MBx32 8MBx32 96MB 8MBx32 8MBx32 4MBx32 4MBx32 128MB 16MBx32 16MBx32 — — 128MB — — 16MBx32 16MBx32 128MB 8MBx32 8MBx32 8MBx32 8MBx32 136MB 1MBx32 1MBx32 16MBx32 16MBx32 136MB 16MBx32 16MBx32...

  • Page 18: Cache Memory

    Cache Memory The 586ITX system board can sup- port 512KB pipeline burst, direct map write-back cache SRAM. Your system board may come with 512KB cache, which is the maxi- mum cache memory supported by the system board, mounted at loca- tions U5 and U6.
  • Page 19 clock speed is the commonly used speed of Intel processors in the market and is the actual operating clock of the processor (external bus clock x frequency ratio = internal clock speed). AMD processors use the PR-rating system which is the overall processor performance rating.

  • Page 20: Jumper Settings For Intel ® Processors

    ® Jumper Settings for Intel Processors ® Ext. System JP20 Intel Processors Bus Clk JP20 60MHz 1-2 On 90/120/150MHz 66MHz 1-2 Off 100/133/166/200MHz MMX-166/200/233MHz ® Intel Processors Freq. Ratio 90/100MHz/MMX-233MHz 1.5x 1-2 On 1-2 On 120/133MHz 1-2 On 2-3 On 150/166MHz/MMX-166MHz 2-3 On 2.5x...

  • Page 21: Jumper Settings For Amd-K5/K6 Processors

    Jumper Settings for AMD-K5/K6 Processors PR-Rating JP20 Ext. System Bus Clk 1-2 On K5:PR90/PR120/PR150 60MHz JP20 1-2 Off K5:PR100/PR133/PR166 66MHz K6:PR2-166/PR2-200/ 1-2 Off 66MHz PR2-233 PR-Rating Freq. Ratio K5:PR90/PR100/ 1.5x 1-2 On 1-2 On PR120/PR133 K5:PR150/PR166 2-3 On 1-2 On K6:PR2-166 2.5x 2-3 On...

  • Page 22: Installing Upgrade Cpus

    Installing Upgrade CPUs The 586ITX is equipped with a 321- pin Zero Insertion Force (ZIF) socket at location U1 of the system board. This socket is designed for easy removal of an old CPU and easy insertion of an upgrade CPU.
  • Page 23 To install an upgrade CPU, do the following: 1. Make sure the handle on the side of the ZIF socket is up. To raise the handle, push it down, slightly pull it out to the side, then raise it as far as it will go. It may be necessary to initially apply a small amount of sideways force to free the handle from its retaining “...

  • Page 24: Installing A Fan/Heatsink

    3. Position the CPU above the ZIF socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes. Remember that very little force is needed to install the CPU. If the CPU is not easily inserted, verify whether or not pin 1 of the CPU is aligned with pin 1 of the socket.
  • Page 25 Clearance Requirements Your CPU comes with a heatsink mounted on top. To maintain proper airflow once the upgrade is installed on the system board, the CPU and heatsink require certain space clearances. The clearance above the CPU’ s fan/heatsink must be at least 0.4 inches. The clearance on at least 3 of 4 sides of the processor and heatsink must be at least 0.2 inches.

  • Page 26: Jumper Settings For Cmos Clear

    Off: CMOS Clear Jumper Settings for Modem Ring-in Jumper JP21 Modem Ring-in Select The 586ITX board is equipped with an auto detection of receiving mo- dem ring when your system is in power-off situation. Set jumper JP21 pins 1, 2 to on when connect-...

  • Page 27: Factory T Esting Jumpers

    With a modem being installed, you can remotely transmit or access data without physically going to your system. To “ wake up” your sys- tem, follow the steps below. 1. If your ATX power supply has an On/Off switch, set this to On so that even when you have shut down your system, it will always remain in “...

  • Page 28: Ports And Connectors

    Ports and Connectors The 586ITX system board is equipped with two serial ports, one parallel printer port, one shrouded floppy disk header, two shrouded IDE hard disk headers, two connectors for external USB ports, and one IrDA con- nector. Refer to page 12 for the locations of the ports and connectors and pin 1 of these connectors.

  • Page 29: Floppy Disk Drive Controller

    378-37A Hex (default) 278-27A Hex Floppy Disk Drive Controller The 586ITX system board is equipped with a shrouded floppy disk header that supports two standard floppy disk drives. You can install any 360KB, 720KB, 1.2MB, 1.44MB, or 2.88MB floppy disk drives. To prevent improper floppy cable installation, the shrouded floppy disk header has a keying mechanism.

  • Page 30: Ide Hard Disk Interface

    Drive A. IDE Hard Disk Interface The 586ITX system board is equipped with two shrouded PCI IDE headers that will interface four Enhanced IDE (Integrated Drive Elec- tronics) hard disk drives.
  • Page 31 In a few cases, drives from two different manufacturers will not function properly when used together. The problem lies in the hard drives, not the 586ITX system board. Preparing an IDE Drive for Use IDE disk drives are already low-level formatted, with any bad-track er- rors entered, when shipped by the drive manufacturer.

  • Page 32: Universal Serial Bus Connectors

    Using 586ITX with CD-ROM Drives If you encountered problems while using an ATAPI CD-ROM drive that is set in Master mode, please set the CD-ROM drive to Slave mode.

  • Page 33: Irda Connector

    Connect your IrDA cable to connector CN4 on the 586ITX sys- tem board. Make sure “ Onboard IR Controller” in the Integrated Periph- erals setup of the Award BIOS is Enabled.

  • Page 34: Installing Expansion Cards

    Installing Expansion Cards The 586ITX system board is equipped with 3 dedicated PCI slots, 2 dedicated 16-bit ISA slots and 1 shared PCI/ISA slot. All PCI and ISA slots are bus masters.

  • Page 35: Chapter 3: Software Installation

    Chapter 3 Software Installation After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen: Press DEL to enter setup If the message disappears before you respond, restart your system or press the “...

  • Page 36: Standard Cmos Setup

    ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS SUPERVISOR PASSWORD BIOS FEATURES SETUP CHIPSET FEATURES SETUP USER PASSWORD POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION HDD LOW LEVEL FORMAT PNP/PCI CONFIGURATION LOAD FAIL-SAFE SETTINGS SAVE &...
  • Page 37 Date The date format is <day>, <month>, <date>, <year>. Displays a day, from Sunday to Saturday Displays the month, from January to December Month Displays the date, from 1 to 31 Date Displays the year, from 1900 to 2099 Year Time The time format is <hour>, <minute>, <second>.
  • Page 38 If the controller of the HDD interface is ESDI, you must select “ Type 1” . If the controller of the HDD interface is SCSI, you must select “ None” . If you select Type “ Auto” , the BIOS will auto-detect the HDD & CD-ROM drive at the POST stage and show the IDE for the HDD &...
  • Page 39 Video This category selects the type of video adapter used for the primary system monitor. Although secondary monitors are supported, you do not have to select the type in Setup. The default setting is EGA/VGA (BIOS default, Setup default). Enhanced Graphics Adapter/Video Graphics Array. For EGA, EGA/VGA VGA, SVGA and PGA monitor adapters.

  • Page 40: Bios Features Setup

    Base This refers to the amount of base or conventional memory Memory installed on the system board. Extended This is the amount of memory located above 1MB in the Memory memory address map of the CPU. Other This memory size refers to the memory located in the ad- Memory dress space between 640K and 1024K.
  • Page 41 ! WARNING ! Disk boot sector is to be modified Type “ Y” to accept write or “ N” to abort write Award Software, Inc. After seeing this message, if necessary, you will be able to run an anti- virus program to locate and remove the problem before any damage is done.
  • Page 42 Boot Sequence This category determines which drive to search first for the disk operat- ing system (i.e. DOS). The default is A, C, SCSI. The options are: A, C, SCSI; C, A, SCSI; C, CDROM, A; CDROM, C, A; D, A, SCSI; E, A, SCSI; F, A, SCSI; SCSI, A, C; SCSI, C, A; or C only. Swap Floppy Drive Enabled When this option is enabled and the system is booting from...
  • Page 43 Security Option This category allows you to limit access to your system and Setup or just to Setup. System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt.

  • Page 44: Chipset Features Setup

    Enabled Optional shadow is enabled. Disabled Optional shadow is disabled. Chipset Features Setup This section gives you instructions on how to configure the system based on the specific features of the chipset. This chipset manages bus speeds and access to system memory resources. It also coordinates communications between the conventional ISA bus and the PCI bus.
  • Page 45 ROM PCI/ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Power Management : User Define ** Reload Global Timer Events ** : Enabled IRQ [3-7, 9-15], NMI PM Control by APM : Yes : Disabled Primary IDE 0 Video Off Method : V/H SYNC+Blank Primary IDE 1 : Disabled...
  • Page 46 Video Off Method This determines the manner in which the monitor is blanked. This selection will cause the system to turn off the vertical and SYNC + horizontal synchronization ports and write blanks to the video Blank buffer. Blank This option only writes blanks to the video buffer. Screen DPMS Initializes display power management signaling.
  • Page 47 Suspend When enabled and after the set time of system inactivity, the Mode CPU and onboard peripherals will be shut off. This is used to define the continuous HDD idle time that Power elapses before the HDD enters the power saving mode (mo- Down tor off).

  • Page 48: Pnp/Pci Configuration Setup

    Break Event From Suspend and Reload Global Timer Events These are I/O events whose occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything which occurs to a device which is configured as enabled, even when the system is in a power saving mode.
  • Page 49 Select this option when your operating system is Windows 95. Select this option when your operating system is not Windows 95. (default) Resources Controlled By The Award Plug and Play BIOS has the capacity to automatically con- figure all of the boot and Plug and Play compatible devices. Auto The system will automatically detect the settings for you.

  • Page 50: Load Fail-Safe Settings

    Assign IRQ for VGA If Enabled, the system will automatically set an IRQ for the VGA card installed. Your VGA card will need an IRQ address only when using the video capture function of the card. If you are not using this function and a new device requires an IRQ address, you can set this function to Disabled.

  • Page 51: Integrated Peripherals

    Integrated Peripherals ROM PCI/ISA BIOS INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. IDE HDD Block Mode : Enabled Parallel Port Mode : Normal IDE Primary Master PIO : Auto IDE Primary Slave PIO : Auto IDE Secondary Master PIO : Auto IDE Secondary Slave PIO : Auto IDE Primary Master UDMA : Auto...
  • Page 52 IDE Primary Master/Slave UDMA and IDE Secondary Master/Slave UDMA These categories allow you to set the Ultra DMA in use. When Auto is selected, the BIOS will select the best available option after checking your hard drive or CD-ROM. Auto The BIOS will automaticaly detect the settings for you.
  • Page 53 UART 2 Mode The 586ITX system board supports IrDA function for wireless connec- tivity between your computer and peripheral devices. To use the IrDA function, follow the steps below. 1. Connect your IrDA cable to connector CN4 of the 586ITX system board.

  • Page 54: Supervisor Password

    Supervisor Password If you want to protect your system and setup from unauthorized entry, set a supervisor’ s password with the “ System” option selected in the BIOS Features Setup. If you want to protect access to setup only, but not your system, set a supervisor’...

  • Page 55: Ide Hdd Auto Detection

    To set, confirm, verify, disable or delete a user’ s password, follow the procedures described in the section “ Supervisor Password” . If you for- get your password, refer to the procedure described in the same sec- tion. IDE HDD Auto Detection This option detects the hard disk parameters for the hard disk drives installed in your system.
  • Page 56 Normal Mode Normal mode is the generic access mode in which neither the BIOS nor the IDE controller will make any transformations during hard-drive ac- cess. The maximum number of cylinders, heads and sectors for Normal mode are 1024, 16 and 63, respectively. no.

  • Page 57: Hdd Low Level Format

    Large Mode Large mode is the extended HDD access mode supported by the sys- tem board. Some IDE HDDs have more than 1024 cylinders without LBA support (in some cases, you may not want the LBA mode). This system board provides another alternative to support these kinds of HDDs.

  • Page 58: Save & Exit Setup

    ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. Hard Disk Low Level Format Utility No. CYLS HEAD SELECT DRIVE BAD TRACK LIST PREFORMED Current select drive is : C DRIVE: C CYLINDER: 0 HEAD: 0 LANDZ SECTOR SIZE CYLS HEAD RECOMP MODE...

  • Page 59: System Error Report

    Type “ Y” and press <Enter>. The system will reboot and you will once again see the initial diagnostics on the screen. If you wish to make any changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del> after memory testing is done. System Error Report When the BIOS encounters an error that requires the user to correct something, either a beep code will sound or a message will be dis-...
  • Page 60 DISPLAY SWITCH IS SET INCORRECTLY The display switch on the motherboard can be set to either mono- chrome or color. This indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct, either turn off the system and change the jumper or enter Setup and change the VIDEO selection.

  • Page 61: Driver Installation

    Memory test fail The BIOS reports memory test fail if the memory has error(s). Driver Installation To install the IDE drivers supported by the 586ITX system board, please refer to the “ Readme” file contained in the provided diskette for detail information.
  • Page 62 Win95 OSR2.1, there may be some warning messages appearing while you boot up your system. This problem occurs for Win95 has not recognized the TX chipset on the 586ITX board. To change files for Win95 by knowing TX chipset, you may need to change some filies in Win95.
  • Page 63 7. After finishing copy, click "Control Panel" under Setting of Start. 8. Choose "Device Manager" on the top of "System Properties" screen. 9. Choose "View devices by connection" and click on "Plug & Play BIOS". 10. Click on "PCI BUS" and choose "Remove" on the buttom of the screen, then click "OK".

  • Page 64: Chapter 4: Troubleshooting Checklist

    Chapter 4 Troubleshooting Checklist This chapter of the manual is designed to help you with problems that you may encounter with your personal computer. To efficiently troubleshoot your system, treat each problem individually. This is to ensure an accurate diagnosis of the problem in case a problem has multiple causes.
  • Page 65 Hard Drive Hard disk failure. 1. Make sure the correct drive type for the hard disk drive has been entered in the BIOS. 2. If the system is configured with two hard drives, make sure the bootable (first) hard drive is configured as Master and the second hard drive is configured as Slave.
  • Page 66 3. Verify that the attached serial device works by attaching it to a serial port that is working and configured correctly. If the serial device does not work, either the cable or the serial device has a problem. If the serial device works, the problem may be due to the onboard I/O or the address setting.

  • Page 67: Appendix A: Types Of Modules

    Appendix A Types of Modules The following modules have been tested with this board. Most untested brands will work but a few may fail to do so. DIMM Brand Chip Number Fujitsu 1MBx64 D4516161G5-7JF 1MBx64 D4516161G5-7JF 2MBx64 KM416S1120AT-G12 2MBx64 D4516821G5-A12-7F 2MBx64 Mitsubishi M5M4V16S30CTP...
  • Page 68 Brand SIMM Chip Number 4MBx32/x36 Mitsubishi 422A06-70 4MBx32/x36 Hitachi 5117400AS-70 4MBx32 4217400-60 4MBx32 4217405-70 (EDO) 8MBx32 4217405-60 (EDO) 16MBx32 71C16100AJ6...

  • Page 69: Appendix B: Memory And I/O Maps

    Appendix B Memory and I/O Maps Memory Address Map Address Name Function 0000000 to 640KB System System Board Memory 009FFFF Board RAM 00A0000 to 128KB Video Reserved for Graphics 00BFFFF Display Memory Display Memory 00C0000 to 160KB I/O Reserved for ROM on 00E7FFF Expansion ROM I/O Adapter Card...
  • Page 70 I/O Address Map I/O Address Function 0000-001F DMA Controller 1, 8237A-5 0020-003F Interrupt Controller 1, 8259A, Master 0040-005F Timer, 8254-2 0060-006F 8742 (Keyboard Controller) 0070-007F Real-time Clock, NMI (Non-maskable Interrupt) Mask 0080-009F DMA Page Memory, 74LS612 00A0-00BF Interrupt Controller 2, 8259A 00C0-00DF DMA Controller 2, 8237A-5 00E8...

  • Page 71: Appendix C: Connector Pin Assignments

    Appendix C Connectors Connectors COM 1 serial port Floppy disk drive connector COM 2 serial port IrDA connector PS/2 keyboard port PS/2 mouse port Parallel printer port ATX power connecter USB 1 connector USB 2 connector JP19 Fan controller...
  • Page 72 Primary IDE hard disk drive connector Secondary IDE hard disk drive connector Keylock connector Speaker connector Reset switch connector SMI switch connector Power switch connector Green LED connector HDD LED connector ATX LED connector...
  • Page 73 Pin Assignments JP8 - USB 1 connector JP9 - USB 2 connector Function Function -Data -Data +Data +Data Ground Ground Ground CN6 - PS/2 mouse port CN4 - IrDA connector Function Function Mouse Data IrTX N. C. Ground Ground IrRXL N.C.
