DFI 586ITX User Manual page 73

Pin Assignments
JP8 - USB 1 connector
Pin Function
1 +5V
2 -Data
3 +Data
4 Ground
5 Key
CN6 - PS/2 mouse port
Pin Function
1 Mouse Data
2 N. C.
3 Ground
4 +5V
5 Mouse Clock
6 N. C.
CN8 - ATX power connector
Pin
Function
1
N. C.
2
N. C.
3
Ground
4
+5V
5
Ground
6 +5V
7 Ground
8 PW-OK
9 5VSB
10 +12V
JP9 - USB 2 connector
Pin Function
1 +5V
2 -Data
3 +Data
4 Ground
5 Ground
CN4 - IrDA connector
Pin Function
1 IrTX
2 Ground
3 IrRXL
4 N.C.
5 +5V
Function
Pin
N. C.
11
-12V
12
Ground
13
PS-ON
14
Ground
15
Ground
16
Ground
17
-5V
18
+5V
19
+5V
20
73
