- Page 1 RL830-C602/C604 EATX Industrial Motherboard User’s Manual A28800341...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents Cooling Fan Connectors................22 Power Connectors ..................22 Front Panel Connector ................23 XDP Ports ....................24 Expansion Slots ..................24 Copyright ......................2 LPC Debug Port ..................25 Chassis Intrusion Connector ................ 25 Trademarks Battery ....................... 26 ...................... -
Page 4: About This Manual
About this Manual Static Electricity Precautions An electronic file of this manual is included in the CD. To view the user’s manual in the CD, It is quite easy to inadvertently damage your PC, system board, components or devices even insert the CD into a CD-ROM drive. -
Page 5: About The Package
About the Package The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One RL830 motherboard • One Serial ATA data cable • One I/O shield •... -
Page 6: Chapter 1 - Introduction
Chapter 1 Chapter 1 - Introduction Internal I/O • 1 connector for 2 external USB 2.0/1.1 ports Specifications • 1 Embedded USB connector for eUSB SSD • 1 vertical Type A USB 2.0 port • 1 connector for an external RS232 serial port Processor •... -
Page 7: Features
Chapter 1 • Wake-On-USB Features This function allows you to use a USB keyboard or USB mouse to wake up a system from the • Watchdog Timer S3 (STR - Suspend To RAM) state. The Watchdog Timer function allows your application to regularly “clear” the system at the set time interval. -
Page 8: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Important: Board Layout Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in boards, and other components. Perform installation procedures at an ESD workstation only. If such a station is not available, you can provide some ESD protection by wear- ing an antistatic wrist strap and attaching it to a metal part of the system chassis. -
Page 9: Installing The Dimm Module
DIMMs in the same channel are identical. Notch Important: When you are installing the memory modules on the system board, you must popu- late them in the DDR3_1, DDR3_3, DDR3_5, DDR3_7, DDR3_9, DDR3_11, DDR3_13 or DDR3_15 sockets first. Chapter 2 Hardware Installation www.dfi.com... -
Page 10: Cpu
8. The ejector tabs at the ends of the socket will automatically snap into the locked position to hold the module in place. Note: The system board used in the following illustrations may not resemble the actual board. These illustrations are for reference only. Chapter 2 Hardware Installation www.dfi.com... -
Page 11: Installing The Cpu
4. Unlock the socket by push- ing the load lever down, moving it sideways until it Retention tab is released from the reten- tion tab; then lift the load lever up. Retention tab Load lever Chapter 2 Hardware Installation www.dfi.com... - Page 12 Alignment key The CPU’s notch will at the same time fit into the socket’s alignment key. Alignment key Important: The CPU will fit in only one orientation and can easily be inserted without exerting any force. Chapter 2 Hardware Installation www.dfi.com...
-
Page 13: Installing The Fan And Heat Sink
4 mounting holes around board. the socket. CPU Fan connector 3. Orient the heat sink such CPU Fan that the CPU fan’s cable is connector nearest the CPU fan con- nector. CPU Fan connector Chapter 2 Hardware Installation www.dfi.com... -
Page 14: Jumper Settings
USB device to wake up the system. reset the BMC controller whenever problem occurs. Important: If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB ports, the +5V_standby power source of your power supply must support ≥1.5A. For 3 or more USB ports, the +5V_standby power source of your power supply must support ≥2A. Chapter 2 Hardware Installation www.dfi.com... -
Page 15: Clear Cmos Data
2. Set JP7 pins 2 and 3 to On. Wait for a few seconds and set JP7 back to its default setting, pins 1 and 2 On. 3. Now plug the power cord and power-on the system. Chapter 2 Hardware Installation www.dfi.com... -
Page 16: Power-On Select
5 seconds (power flicker). JP2 (for COM 2) is used to configure the Serial COM port to pure RS232 or RS232 with power. The pin functions of COM 2 will vary according to JP2’s setting. Chapter 2 Hardware Installation www.dfi.com... -
Page 17: Cpu0/Cpu1 Debug
Chapter 2 CPU0/CPU1 Debug 1-2 On: Force JTAG by pass of CPU 2-3 On: Normal (default) JP8 (for CPU1) and JP9 (for CPU0) allow you to debug the CPU procrssor whenever encounter- ing problems. Chapter 2 Hardware Installation www.dfi.com... -
Page 18: Rear Panel I/O Ports
The rear panel I/O ports consist of the following: • 1 Serial COM port • 1 VGA port COM 2: RS232 • 4 USB 2.0 ports • 4 RJ45 LAN ports CTS- RTS- DSR- DTR- DCD- COM 1 and COM 2 ports are fixed at RS232. JP2 (for COM 2) is used to configure the Serial COM port to pure RS232 or RS232 with power. Refer to “COM2 RS232/Power Select“ in this chapter for more information. The serial ports are RS232 asynchronous communication ports with 16C550A-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. Connecting External Serial Ports Your COM port may come mounted on a card-edge bracket. Install the card-edge bracket to an available slot at the rear of the system chassis then insert the serial port cable to the COM connector. Make sure the colored stripe on the ribbon cable is aligned with pin 1 of the COM connector. BIOS Setting Configure the serial COM ports in the Advanced menu (“AST1400 Super IO Configuration” submenu) of the BIOS. Refer to the chapter 3 for more information. Chapter 2 Hardware Installation www.dfi.com... -
Page 19: Graphics Interface
12) is the USB Drive Security for securing USB flash drive. The additional USB port may be mounted on a card-edge bracket. Install the card-edge bracket to an available slot at the rear of the system chassis and then insert the USB port cables to a connector. BIOS Setting Configure these onboard USB devices in the Advanced menu (“USB Configuration” submenu) of the BIOS. Refer to the chapter 3 for more information. Chapter 2 Hardware Installation www.dfi.com... -
Page 20: Rj45 Lan Ports
Refer to your operating system’s manual or documentation for more information. Wake-On-USB Keyboard/Mouse The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state. To use this function: LAN 1 LAN 0 LAN 1 • Jumper Setting LAN 0 LAN 3 LAN 2-3 JP3, JP4, JP5 and JP6 must be set to “2-3 On: +5V_standby”. Refer to “USB Power Select” in LAN 2 this chapter for more information. Important: If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB ports, the +5V_standby power source of your power supply must support ≥1.5A. For 3 or more USB ports, the +5V_standby power source of your power supply must support ≥2A. Features • Intel 82580 PCI Express Gigabit Ethernet controller ® The four LAN ports allow the system board to connect to a local area network by means of a network hub. BIOS Setting Configure the onboard LAN ports in the Advanced menu of the BIOS. Refer to the chapter 3 for more information. Driver Installation Install the LAN drivers. Refer to the chapter 4 for more information. Chapter 2 Hardware Installation www.dfi.com... -
Page 21: I/O Connectors
Chapter 2 I/O Connectors The Serial ATA connectors are used to connect Serial ATA devices. Connect one end of the Se- rial ATA data cable to a SATA connector and the other end to your Serial ATA device. SATA (Serial ATA) Connectors BIOS Setting Configure the Serial ATA drives in the Advanced menu (“SATA Configuration”... -
Page 22: Cooling Fan Connectors
Chapter 2 Cooling Fan Connectors Power Connectors Ground +12V Power Sense +12V Speed Control Ground +12V Power +12V CPU Fan CPU Fan Ground +12V Sense Speed Control power System Fan 1/2/3/4/5/7 Use a power supply that complies with the ATX12V Power Supply Design Guide Version 1.1. An ATX12V power supply unit has a standard 24-pin ATX main power connector that must be inserted into the 24-pin connector. -
Page 23: Front Panel Connector
Chapter 2 Front Panel Connector The pin functions of the front panel connector are listed below. Pins Pin Assignment Pins Pin Assignment +3VDU +3VDU +5VDU PWR-LED +3.3V HDD-LED PWR-BTN LED_NIC_LINK1_0_LINKUP LED_NIC_LINK1_0_ACT RST-SW SMB_SENSOR_3V3STBY_DATA SMB_SENSOR_3V3STBY_CLK Case Open +3VDU LED_NIC_LINK3_2_LINKUP LED_NIC_LINK3_2_ACT Front Panel HDD-LED - HDD LED This LED will light when the hard drive is being accessed. -
Page 24: Xdp Ports
Chapter 2 XDP Ports Expansion Slots PCIe 1, PCIe x8 PCIe 2, PCIe x16 PCIe 3, PCIe x8 PCIe 4, PCIe x16 PCIe 5, PCIe x16 PCIe 6, PCIe x16 PCI Express x16 Slot CPU XDP port PCH XDP port Install PCI Express x16 graphics card, that comply to the PCI Express specifications, into the PCI Express x16 slot. -
Page 25: Lpc Debug Port
Chapter 2 LPC Debug Port Chassis Intrusion Connector Chassis Intrusion LPC Debug Port Signal Ground The LPC connector is used for the debug function and its pin functions are listed below. Pins Pin Assignment Pins Pin Assignment The board supports the chassis intrusion detection function. Connect the chassis intrusion sensor cable from the chassis to this connector. -
Page 26: Battery
Chapter 2 Battery Battery The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source of power when the main power is shut off. Safety Measures • Danger of explosion if battery incorrectly replaced. • Replace only with the same or equivalent type recommend by the manufacturer. •... -
Page 27: Chapter 3 - Bios Setup
Chapter 3 Chapter 3 - BIOS Setup Legends Overview Keys Function The BIOS is a program that takes care of the basic level of communication between the CPU and peripherals. It contains codes for various advanced features found in this system board. Right and Left arrows Moves the highlight left or right to select a menu. -
Page 28: Ami Bios Setup Utility
Chapter 3 AMI BIOS Setup Utility Advanced The Advanced menu allows you to configure your system for basic operation. Some entries are Main defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. - Page 29 Chapter 3 ACPI Settings Trusted Computing This section is used to configure the System ACPI settings. This section configures settings relevant to Trusted Computing innovations. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Advanced Enables or Disables Sys-...
- Page 30 Chapter 3 WHEA Configuration PC Health Status This section is used to configure the general WHEA settings. This section displays the hardware health monitor. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Advanced Enable or disable...
- Page 31 Chapter 3 CPU Configuration Intel Virtualization Technology This section is used to configure the CPU. It will also display the detected CPU information. When this field is set to Enabled, the VMM can utilize the additional hardware capabili- ties provided by Vanderpool Technology. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
- Page 32 Chapter 3 CPU Power Management Configuration EIST This field configures parameters of the CPU power management. Enables or disables the Enhanced SpeedStep Technology. Turbo Mode Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Enables or disables the Turbo Mode. Enable the power manage- CPU Power Management Confi...
- Page 33 Chapter 3 When AHCI or RAID mode is selected in the SATA Mode Selection, it will display the SATA Configuration following information: This section is used to configure the settings of SATA device. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
- Page 34 Chapter 3 USB Configuration Intel TXT(LT-SX) Configuration This section is used to configure the parameters of the USB device. This field displays the configuration of the Intel Trusted Execution Technology. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
- Page 35 Chapter 3 AST1400 Super IO Configuration This section is used to configure the I/O functions supported by the onboard Super I/O chip. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Advanced Restore AC Power Loss...
- Page 36 Chapter 3 Network Stack Ipv4 PXE Support This section is used to enable or disable UEFI network stack. When enabled, Ipv4 PXE boot supports. When disabled, Ipv4 PXE boot option will not be created. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Ipv6 PXE Support Advanced Network Stack...
- Page 37 Chapter 3 WatchDog Configuration Intel(R) 82580 Gigabit Network Connection - 00:01:29:11... This field is used to enable or disable the Watchdog timer function. This section is used to configure parameters of the Gigabit Ethernet device. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
- Page 38 Chapter 3 Intel(R) 82580 Gigabit Network Connection - 00:01:29:22... Intel(R) 82580 Gigabit Network Connection - 00:01:29:33... This section is used to configure parameters of the Gigabit Ethernet device. This section is used to configure parameters of the Gigabit Ethernet device. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
-
Page 39: Chipset
Chapter 3 Chipset Intel(R) 82580 Gigabit Network Connection - 00:01:29:44... This section is used to configure parameters of the Gigabit Ethernet device. This section configures relevant chipset functions. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Advanced Main Advanced... - Page 40 Chapter 3 North Bridge IOH Configuration This section is used to configure the parameters of North Bridge. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Chipset Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Intel(R) VT for Directed I/O Confi guration Intel(R) VT for Directed I/O Confi...
- Page 41 Chapter 3 South Bridge DIMM Information This section is used to configure the parameters of South Bridge. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Chipset Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. CPU Socket 0 DIMM Information Chipset Not Present Node 0 Ch 0 Dimm 0...
- Page 42 Chapter 3 Onboard SATA RAID Oprom/Driver USB Configuration Controls whether to enable the onboard SATA option ROM or EFI driver. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Chipset High Precision Timer USB Confi guration Enabled/Disabled All USB Enables or disables the High Precision Event Timer.
-
Page 43: Boot
Chapter 3 Boot ME Subsystem This section is used to configure the parameters of ME Subsystem. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Enables or disables Quiet Chipset Quiet Boot... -
Page 44: Security
Chapter 3 Security CSM Parameters Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Main Advanced Chipset Boot Security Save & Exit This option controls if Launch CSM [Enabled]... -
Page 45: Save & Exit
Chapter 3 Save & Exit Restore User Defaults To restore user default to all the setup options, select this field and then press Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. <Enter>. A dialog box will appear. Select Yes to restore user default. Main Advanced Chipset... -
Page 46: Updating The Bios
Chapter 3 Updating the BIOS To update the BIOS, you will need the new BIOS file and a flash utility, AFUDOS. EXE. Please contact technical support or your sales representative for the files. To execute the utility, type: A:> AFUDOS BIOS_File_Name /b /p /n then press <Enter>. -
Page 47: Chapter 4 - Supported Software
CD screen did not appear), please go directly to the root directory of the CD and double-click “Setup”. 1. Setup is ready to install the utility. Click Next. 2. Read the license agreement then click Yes. Chapter 4 Supported Software www.dfi.com... - Page 48 To install the driver, click “Aspeed Graphics Drivers” on the main menu. 1. Prepare to install the driver. 2. Setup is ready to install the driver and then click “Next”. 4. Click Finish to exit setup. 3. Click “Install“ to begin the installation. Chapter 4 Supported Software www.dfi.com...
-
Page 49: Intel Lan Drivers
“Finish.” 2. Click “I accept the terms in the license agreement” and then click “Next.” 6. Click “Yes“ to restart your system. 3. Select the program featuers you want installed and then click “Next.” Chapter 4 Supported Software www.dfi.com... -
Page 50: Intel Management Engine Interface
To install the driver, click “Intel Management Engine Interface” on the main menu. 1. Setup is ready to install the driver. Click “Next.” 5. After completing the instal- lation, click “Finish.” 2. Read the license agreement then click “Yes.” Chapter 4 Supported Software www.dfi.com... -
Page 51: Intel Rapid Storage Technology
To install the driver, click “Intel Rapid Storage Technology” on the main menu. 1. Setup is now ready to install the utility. Click “Next.” 4. After completing the instal- lation, click “Finish.” 2. Read the warning and then click “Yes.” Chapter 4 Supported Software www.dfi.com... - Page 52 Restarting the system will allow the new software installation to take effect. 4. Go through the readme document for system requirements and instal- lation tips. Then, click “Next.” 5. Setup is now installing the utility. Click “Next” to continue. Chapter 4 Supported Software www.dfi.com...
-
Page 53: Dfi Utility
DFI Utility 3. Click “Install” to begin the installation. DFI Utility provides information about the board, Watchdog,and DIO. To access the utility, click “DFI Utility” on the main menu. Note: If you are using Windows 7, you need to access the operating system as an administrator to be able to install the utility. - Page 54 Chapter 4 The DFI Utility icon will appear on the desktop. Double-click the icon to open the utility. Information HW Health Set HW Health WatchDog Chapter 4 Supported Software www.dfi.com...
- Page 55 32-bit and 64-bit operating systems. The path to the drivers are shown below. 32-bit CD Drive:\AHCI_RAID\F6FLOPPY\f6flpy32 64-bit CD Drive:\AHCI_RAID\F6FLOPPY\f6flpy64 2. The setup program is now ready to install the utility. Click Next. 3. Click “I accept the terms in the license agreement” and then click “Next”. Chapter 4 Supported Software www.dfi.com...
- Page 56 Visual C++ package prior to installing the utility. Click Install. 5. Select a setup type and then click 8. The setup program is currently Next. installing the Microsoft Visual C++ package. 9. Click Finish. 6. Click Install. Chapter 4 Supported Software www.dfi.com...
- Page 57 To install the reader, click “Adobe Acrobat Reader 9.3” on the main menu. 1. Click Next to install or click Change Destination Folder to select another folder. 2. Click Install to begin installa- tion. 3. Click Finish to exit installation. Chapter 4 Supported Software www.dfi.com...
-
Page 58: Appendix A - Troubleshooting
Browse, select the folder The downloaded driver files and then click Next. should include iaahci.cat, iaAHCI.inf, iastor.cat, iaStor. inf, IaStor.sys, license.txt and TXTSETUP.OEM. Appendix A NLITE and AHCI Installation Guide www.dfi.com... - Page 59 Drivers and version that you are using Bootable ISO. Click Next. and then click OK. Integrating 64-bit drivers into 32-bit Windows or vice versa will cause file load errors and failed installation. Appendix A NLITE and AHCI Installation Guide www.dfi.com...
- Page 60 RAID/AHCI the installation. controllers and then click When the program is finished applying the changes, click Next. Click Next. Appendix A NLITE and AHCI Installation Guide www.dfi.com...
- Page 61 Or you can choose to burn it directly to a disc by selecting the Direct Burn mode under the General section. Select the optical device and all other necessary settings and then click Next. Appendix A NLITE and AHCI Installation Guide www.dfi.com...
- Page 62 Controllers, then select Update Driver. 7. Select “Don’t search. I will choose the driver If the controller you to install” and then click selected did not work, try Next. selecting another one. Appendix A NLITE and AHCI Installation Guide www.dfi.com...
- Page 63 SATA control- AHCI Controller of your ler from IDE to AHCI. By hardware device and doing so, Windows will then click Next. work normally with the SATA controller that is in AHCI mode. Appendix A NLITE and AHCI Installation Guide www.dfi.com...
-
Page 64: Appendix B - Watchdog Sample Code
Appendix B Appendix B - Watchdog Sample Code Watch Dog ISI Programing Guide ; Using DFI Utility (ISIDll.dll) library function WD_Init WD_SerTimerValue WD_GetTimerValue -------------------------------------------------------------- WD_Init function Initial the Watch Dog Timer Module Syntax Int WD_Init(void); Return value If the return value isn’t NULL ,the initial procedure failed. -
Page 65: Appendix C - System Error Message
Appendix C Appendix C - System Error Message Hard Disk(s) fail (20) When the BIOS encounters an error that requires the user to correct something, either a beep HDD initialization error. code will sound or a message will be displayed in a box in the middle of the screen and the message, PRESS F1 TO CONTINUE, CTRL-ALT-ESC or DEL TO ENTER SETUP, will be shown in Hard Disk(s) fail (10) the information box at the bottom. -
Page 66: Appendix D - Troubleshooting
Appendix D Appendix D - Troubleshooting Checklist The picture seems to be constantly moving. Troubleshooting Checklist 1. The monitor has lost its vertical sync. Adjust the monitor’s vertical sync. 2. Move away any objects, such as another monitor or fan, that may be creating a magnetic This chapter of the manual is designed to help you with problems that you may encounter field around the display. -
Page 67: Hard Drive
Appendix D Hard Drive System Board 1. Make sure the add-in card is seated securely in the expansion slot. If the add-in card is Hard disk failure. loose, power off the system, re-install the card and power up the system. 1.
