Jumper Settings For Intel ® Processors - DFI 586ITX User Manual

Jumper Settings for Intel
® Ext. System
Intel Processors
Bus Clk
60MHz
90/120/150MHz
66MHz
100/133/166/200MHz
MMX-166/200/233MHz
®
Intel Processors
Freq. Ratio
90/100MHz/MMX-233MHz
120/133MHz
150/166MHz/MMX-166MHz
200MHz/MMX-200MHz
Core Voltages JP13
3.2V 9-10 On
2.8V 7-8 On
2.9V 5-6 On
3.3V* 3-4 On
3.5V
1-2 On
*
Default
Chipset Voltages JP15
3.5V
1-2 On
3-4 On
3.3V*
*
Default
20
®
Processors
JP20
JP20
1-2 On
1-2 Off
JP1 JP2
1.5x 1-2 On
1-2 On
2x 1-2 On
2-3 On
2-3 On
2.5x 2-3 On
3x 1-2 On 2-3 On
1 2
9 10
JP13
2
1
4
3
JP15
JP2 JP1
