IDE Primary Master/Slave UDMA and IDE Secondary Master/Slave
UDMA
These categories allow you to set the Ultra DMA in use. When Auto is
selected, the BIOS will select the best available option after checking
your hard drive or CD-ROM.
Auto The BIOS will automaticaly detect the settings for you.
The BIOS will not detect these categories.
Disabled
On-Chip Primary PCI IDE and On-Chip Secondary PCI IDE
These categories allow you to enable or disable the primary and sec-
ondary IDE controller. The default is Enabled. Select Disabled if you
want to add a different hard drive controller.
USB Keyboard Support
This category allows you to enable or disable the USB Keyboard Sup-
port. The default is Disabled. Select Enabled if you are in MS-DOS and
your keyboard is not working.
Onboard FDC Controller
Enables the onboard floppy disk controller.
Enabl e d
Disables the onboard floppy disk controller.
Disabled
Onboard Serial Port 1 and Onboard Serial Port 2
Auto
3F8/IRQ4, 2F8/IRQ3
3E8/IRQ4, 2E8/IRQ3
Disabled
52
The system will automatically select an I/O address
for the onboard serial port 1 and serial port 2.
Allows you to manually select an I/O address for
the onboard serial port 1 and serial port 2.
Disables the onboard serial port 1 and/or serial port 2.
