3 - Hopper Module Replacement Procedure

3 Hopper Module Replacement Procedure
3.1

How to Prepare the Device for Removing / Re-installing Modules

To prepare the device for removing / re-installing modules, follow these steps in accordance with standard
safety practices:
1) Offer the customer the opportunity to remove any proprietary or security-sensitive consumables from
the device, including card stock, image printer ribbons, indent cartridges, and tipper foils. Some
consumables contain negative imprints of cardholder data and must be handled securely.
2) Make sure you have adequate lighting around the device, and / or plan to use a flashlight.
3) Make sure you have a safe location to place removed parts and replacement parts.
4) Make sure the device is powered up and connected to the network.
5) Park the hopper transport at the front of the device by following these steps:
a) From the touchscreen, press the
b) Press the
Maintenance
c) Press the
Remove Hopper
6) If the relevant replacement procedure requires you to use the touchscreen user interface, perform
those steps while the device is still powered up and connected to the network.
7) Power down the device.
8) Disconnect the device's power cable from the AC socket-outlet, then disconnect the power cable and
network cable from the rear of the device.
9) If necessary, unlock or disconnect any security hardware from the device.
10) If the replacement procedure requires you to remove the device's top access door or the entire cover,
or requires rear access to the device, make sure you have adequate clearance around the device.
Depending on the installation location, you may need to move the device to a service location.
ExpressCard 2000| Instant Issuance Card Personalization System | Hopper Module Replacement Procedure
Menu button.
button to open the
Maintenance Menu
button and wait for the hopper shuttle to finish moving.
Page 7 of 42 (D99875700-30)
