3 - Hopper Module Replacement Procedure
25) Tuck the
HOPPER SHUTTLE EXC HOME SENSOR
circuit board to prevent it from snagging on moving parts.
26) Clip the
HOPPER SHUTTLE EXC HOME SENSOR
the device, and take up any slack along its length.
ExpressCard 2000| Instant Issuance Card Personalization System | Hopper Module Replacement Procedure
cable underneath the
cable into the cable clip along the right wall of
Page 31 of 42 (D99875700-30)
HOPPER SHUTTLE
