3 - Hopper Module Replacement Procedure
6) Press the
Roller Consume
7) Press the Shuttle to Printer
8) Check to make sure the card is centered at the opening of the image printer.
9) If the card is centered at the printer opening, press the
10) If the card is not centered at the printer opening or if it hit either side of the printer opening or if the
card skewed to one side when entering the printer:
a) Pull on the triangular belt on the front side of the hopper transport to back the card out of the
hopper transport, and remove the card.
b) Navigate to
Menu
page.
c) Enter password
d) Enter password
e) Scroll through the list of options to find the ShuttleHomeToExceptionFeed setting, and select
the number beneath it to bring up the on-screen keypad.
f) If hopper transport was too far toward the rear of the EC2000, decrease the setting, press the
button, and to back to the beginning of this section.
Save
g) If hopper transport was too far toward the front of the EC2000, increase the setting, press the
Save button, and go back to the beginning of this section.
11) Press the
Printer Eject
12) Remove the card from the image printer exit and recycle it.
13) Re-install hopper 2 and hopper 3 in the device.
14) Press the button to return to the
Status
ExpressCard 2000| Instant Issuance Card Personalization System | Hopper Module Replacement Procedure
button.
button.
> >
Settings Edit Config.
, then press the
1234567
, then press the
7654321
button.
Status
Page 42 of 42 (D99875700-30)
Roll to Printer
to open the
Configuration Editing
button.
E
button to open the
E Configuration Editing
page.
button.
password
page.
