Magtek ExpressCard 2000 Manual page 13

3 - Hopper Module Replacement Procedure
14) Unclip the
HOPPER SHUTTLE EXC HOME SENSOR
the top deck plate.
15) If the
HOPPER SHUTTLE EXC HOME SENSOR
carefully thread it out and free it. If it is routed underneath other cables, thread it out until it is free all
the way to the front right corner of the device.
16) Unclip the
HOPPER SHUTTLE EXC HOME SENSOR
corner of the device's case, and route it outside the case to keep it out of the way.
ExpressCard 2000| Instant Issuance Card Personalization System | Hopper Module Replacement Procedure
cable is routed underneath the circuit board,
Page 13 of 42 (D99875700-30)
cable from the cable clip on the right side of
cable from the cable clip in the front right
