Ref. Qty. Description
23 2 AD623ARMZ
USOIC8
24 2 AD820ARZ
SOIC8
25 1 ADSP-21369
SBGA256
26 2 ADG774ABRQ
Z QSOP16
27 2 ADP1864AUJZ
SOT23-6
28 1 PWR
2.5MM_JACK
CON005
29 1 RCA 4X2
CON011
30 2 RCA 1X1
CON012
31 5 MOMENTARY
SWT013
32 3 .05 45X2
CON019
33 2 DIP8 SWT016
34 1 DIP6 SWT017
35 7 DIP4 SWT018
36 1 DB9 9PIN
DB9F
ADSP-21369 EZ-KIT Lite Evaluation System Manual

ADSP-21369 EZ-KIT Lite Bill Of Materials

Reference Designator
U5-U6
U33-U34
U44
U24-U25
VR2,VR5
J4
J5
J7-J8
SW8-SW12
J1-J3
SW1,SW14
SW13
SW2-SW7,SW15
J6
Manufacturer Part Number
ANALOG AD623ARMZ
DEVICES
ANALOG AD820ARZ
DEVICES
ANALOG ADSP-21369KBPZ-3A
DEVICES
ANALOG ADG774ABRQZ
DEVICES
ANALOG ADP1864AUJZ-R7
DEVICES
SWITCH- RAPC712X
CRAFT
SWITCH- PJRAS4X2U01X
CRAFT
SWITCH- PJRAN1X1U01X
CRAFT
PANASONIC EVQ-PAD04M
SAMTEC SFC-145-T2-F-D-A
C&K TDA08H0SB1
CTS 218-6LPST
ITT TDA04HOSB1
TYCO 5747844-4
