Audio Out RCA Connector (J5)
Part Description
Four-channel right angle RCA jack
Two-channel RCA interconnect
cable
Headphone Out Jack (J9)
Part Description
3.5 mm stereo jack
Power Jack (J4)
The power connector (
the EZ-KIT Lite board.
Part Description
2.5 mm power jack
7V power supply
ADSP-21369 EZ-KIT Lite Evaluation System Manual
ADSP-21369 EZ-KIT Lite Hardware Reference
Manufacturer
SWITCHCRAFT
Mating Cable
MONSTER CABLE
Manufacturer
A/D ELECTRONICS
) provides all of the power necessary to operate
J4
Manufacturer
SWITCHCRAFT
DIGI-KEY
Mating Power Supply (shipped with EZ-KIT Lite)
CUI INC.
Part Number
PJRAS4X2U01
BI100-1M
Part Number
ST-323-5
Part Number
RAPC712X-ND
DMS070214-P6P-SZ
2-23
