Technical Data - Automation Dr. Nix CarCheck System PLUS User Manual

CarCheck System PLUS

11.3 Technical data

Measuring range
Resolution
Probe
Measuring method
Standards
Measuring modes
Measuring interval
Measuring accuracy 2)
Memory capacity
Settings
Measuring surface
Radius of curvature
Smallest substrate thickness
Interface
Temperature range
Power supply
Dimensions
Weight
1
Measurements of non-ferromagnetic coating on ferromagnetic substrate (such as lacquer on steel or iron) and
measurements of non-ferromagnetic and non-conductive coatings on non-ferromagnetic and conductive substrate (such as
lacquer on aluminum, zinc, copper or brass)
2 Manufacturer's calibration in regard to the supplied zero reference plates
0 ... 5000µm
0 ... 99.9µm: 0.1µm
100 ... 999µm: 1.0µm
1.0 ... 5.0mm: 0.01mm
Dual probe, automatic substrate selection Fe/NFe
Magnetic (Magnetic flux/Hall effect) or eddy current
DIN EN ISO 2808, ISO 2178, ISO 2360, ASTM B 499, ASTM D 7091
Individual measurement, Measurement with structured storage
ca. 1500ms
0 ... 2000µm: ± (1 µm +2% of the measurement)
> 2000µm: ± 3.5% of the measurement
max. 10 jobs
max. 200 parts
max. 10000 measurements
Radio on/off, display system info, buzzer on/off, date/time, unit
µm/mil, display light on/off, display orientation normal/flipped
min. 20 × 20 mm
convex min. 5mm
concave min. 30mm
Fe: 0.2mm
NFe: 0.05mm
Wireless 2.4GHz, range max. 10m (in free field)
Operation: 0 ... 50°C, storage: –10 ... 60°C
2 AA size batteries 1.5V AlMn, or 2 AA size rechargeable batteries
1.2V
(length × width × height) 68 × 33 × 125 mm
125g incl. batteries
Appendix
1
2
44/44
