Automation Dr. Nix CarCheck System PLUS User Manual page 15

CarCheck System PLUS Appendix
Press the ▼ button while the gauge is switched on to enter the Main menu. Then access the
Date/Time submenu.
Select the Set Time option using the ▼ or ▲ buttons and press ►. The Set Hours option appears.
Use the ▼ or ▲ buttons to set the hour.
Press ► once to select Ok, press ► again to save the hour setting. The Set Minutes option appears.
Follow the instructions as described for setting the hour.
If you wish to cancel, press the ◄ to select Cancel and press ◄ again for confirmation.
Select the Set Time option in the Date/Time submenu using the ▼ or ▲ button and press ►. The
Set Day option appears.
Set the day, month, and year as when setting the time as described above.
4.3.4 Acoustic Signal
The gauge confirms various actions, for example entries via the buttons or measurements, with an
acoustic signal. You can switch off this signal if desired. If the signal is switched off, the symbol
appears in the bottom left of the display.
▼ Main Menu ▼ Setup ► Buzzer
Press the ▼ button while the gauge is switched on to access the Main menu. Then access the
Buzzer. submenu.
Select the desired option using the ▼ or ▲ buttons.
Press ► to activate the option selected. A dot (•) indicates the activated option.
4.3.5 Orientation
You can adjust the orientation of the display to facilitate the handling of the gauge. If, for example, you
connected probe and gauge using the adapter cable and the gauge is lying on a table you can read
the display better if it is rotated by 180°.
▼ Main Menu ▼ Setup ► Display ▼ Orientation
Press the ▼ button while the gauge is switched on to access the Main menu. Then access the
Orientation submenu.
Select the desired orientation using the ▼ or ▲button.
Press ► to activate the selected option. A dot (•) indicates the option activated.
Note:
In the flipped setting, the function of all four buttons is rotated as well to keep their functions in
accordance with the display.
4.3.6 Display Light
The display light is turned on for about 7 seconds each time a measurement is taken. You can switch
of the automated display light to save energy.
▼ Main Menu ▼ Setup ► Display ▼ Backlight
Press the ▼button while the gauge is switched on to access the Main menu. Then access the
Backlight submenu.
Select the desired option using the ▼ or ▲button.
15/44
