CarCheck System PLUS
Attention:
Images that are used in a record cannot be deleted. The software will issue a corresponding warning
message if you try to delete an image that is in use.
7.2.3 The Record View
From the Table view, you can enter the Record view by double clicking an entry in the list of records or
by hitting the E key after selecting an entry from the list.
NTER
You can get back to the Table view by clicking on
The Record view shows all the details of a specific record. In this view, vehicle and customer data are
entered, components are defined, and measurements are transmitted and displayed.
The data area of the program window is divided into 6 areas:
1. Record
In this area, the job name, the serial number of the gauge, the record number, and the creation date of
the record are displayed.
The job name is displayed in the display of the gauge when the gauge is in job mode. It can consist of
any letters, digits etc but is limited to 18 characters and may not contain umlauts, accented characters,
or other non-English characters.
Date and serial number are automatically entered by the software and cannot be changed manually.
The record number is automatically created as a consecutive number by the software, but can also be
entered manually. In this case, care must be taken to keep record numbers unique, i. e. a record
number may not occur twice in the database.
There is also a comment entry field in the Record area, where annotations, comments etc. can be
entered.
2. Checker, Vehicle, Customer, Appraiser
Enter the header data, for example the name of the inspector and the license number of the inspected
vehicle, in these areas.
.
