CarCheck System PLUS Appendix
To simplify the data entry in case you have to re-enter data that is already present in the database, the
software automatically suggests matching database entries during data entry.
This feature can save significant time because for example the inspector or the inspecting company is
usually the same for most or all of the records.
As soon as you enter the first letter in any field of an area, a list of matching entries in the database
appears:
With every entered letter, the list is reduced to the entries that still match.
Select the appropriate list entry by clicking on it with the mouse. All entries in the corresponding area
will be filled automatically.
After you accepted a suggested database entry, or saved the record, or selected a saved record from
the Table view, the entry fields will appear "grayed out" and cannot be edited. This is to avoid
unintended changes to the saved data.
To change the data, each area has a button to enable editing of the entries:
In the Appraiser area, a logo can be added to the record or removed from it with 2 buttons:
This logo will be printed together with the rest of the header data.
3. Measurement Data
This area is used to display the measurements of a job, grouped by their respecting components.
Please see on p. 23 for details about the handling of the component list.
See on p. 24 to learn how jobs are transmitted to and from the gauge.
7.2.4 The Record Image View
In this view, an image is assigned to a record. The image can be overlaid with the measurements to
indicate the position of the measurement at the real object.
