CarCheck System PLUS
[no mark] Job not yet started
Job contains measurements but can still be completed
Job contains measurements and can no longer be completed.
Press the ▼ button while the gauge is operating to access the Main menu and switch to the Job
submenu.
Select the desired job using the ▼ or ▲buttons and press ►. The job is being activated. In the top left
of the display, you can see the name of the job, the first measuring area, and the number of
measurements taken:
(Job 001 door fr #0 = right front, door, 0 measurements)
Note:
The number of measurements shown indicates the sum of all measurements that have been saved in
a particular batch for the current and previous jobs stored in the gauge.
Using the ► button, you can switch to the next and any subsequently created car part (batch). Using
the ◄ button, you can switch back through the car parts available.
Having reached the beginning or the end of such a list of car parts, a menu will appear on pressing
either the ◄ or ► buttons. This allows you to select whether to complete the current job or to create a
new batch (car part) . Confirm the selected option by pressing the ► button or cancel the menu using
◄.
While in Job mode, take measurements as described in the section (p 19). A double acoustic signal
confirms that the measurement is being saved. The measurements are allocated to the job and car
part displayed. You can switch between the parts as required and save measurements in almost
infinite numbers (see
5.5.3 Deleting Measurements
In job mode, the menu item Delete Last is added to the Main menu. Using this menu item, you can
delete the last and any previous measurements in reversed order.
Note:
Measurements are stored within the memory consecutively and in the same order they have been
saved. After deleting a measurement, the display shows the measurement now at the end of the list.
The corresponding job and car part are displayed together with this measurement.
When the last remaining measurement of a job is deleted, the last measurement of the previous job
appears in the display together with the corresponding job name and part name.
5.5.4 Closing Jobs
You can cancel job mode as described above by using the ◄ or ► buttons to scroll to the end of the
part list and select the Finish option in the appearing menu.
Alternatively, you can exit job mode by accessing the Main Menu using the ▼ button and selecting the
Finish option within the Job menu.

5.6 Creating Jobs with the CarCheck PLUS Software

Instead of creating a job directly in the gauge, you can use the PC software provided. It offers a much
more convenient way to enter meaningful names for jobs and batches. The entered information is
transmitted from PC to gauge by a simple mouse click via wireless interface.
Find more information in the section on p.
, p.44).
22 ff
