7.3

Advanced

This menu contains the settings for most of the user interfaces in the system.
Feature
CPU Configuration
PCH-FW Configuration
ACPI Setting
NCT6106D Super IO
Configuration
NCT6106D HW Monitor
S5 RTC Wake Settings
Serial Port Console
Redirection
Intel TXT Information
USB Configuration
CSM Configuration
Network Stack Configuration
7.3.1 CPU Configuration
Feature
CPU Configuration
Type
ID
Speed
L1 Data Cache
L1 Instruction Cache
L2 Cache
L3 Cache
L4 Cache
VMX
SMX/TXT
C6DRAM
Software Guard Extensions
BIOS Setup
Options
Options
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Info only
Disabled
Enabled
Disabled
Description
CPU Configuration Parameters.
Configure Management Engine Technology
Parameters.
System ACPI Parameters.
System Super IO Chip Parameters.
Monitor hardware status.
Enable system to wake from S5 using RTC alarm.
Serial Port Console Redirection.
Display Intel TXT Information.
USB Configuration Parameters.
CSM configuration: Enable/Disable, Option ROM
execution settings, etc.
Network Stack Setting.
Description
Enabled/Disabled moving of DRAM contents to PRM
memory when CPU is in C6 state.
Enabled/Disabled Software Guard Extensions (SGX)..
