7.4.2.1 PCI Express Configuration
Feature
PCI Express Configuration
PCIE Device Initial Delay
PCI Express Root Port 5
(Mini-PCIe)
PCI Express Root Port 5
(Mini-PCIe)
ASPM 5
PCIe Speed
PCI Express Root Port 11
(LAN1)
PCI Express Root Port 12
(LAN2)
52
Options
0
Disabled
Enabled
Disabled
L0s
L1
L0sL1
Auto
Auto
Gen1
Gen2
Gen3
Description
The PCIE device initial delay mini second.
Control the PCI Express Root Port.
Set the ASPM Level:
Force L0s – Force all links to L0s State
Auto – BIOS auto configure
Disable – Disables ASPM
Configure PCIe Speed.
BIOS Setup
