7.3.4 NCT6106D Super IO Configuration
Feature
NCT6106D Super IO
Configuration
Super IO Chip
Serial Port 1 Configuration
Serial Port 2 Configuration
Serial Port 3 Configuration
Serial Port 4 Configuration
Serial Port 5 Configuration
WatchDog Count Mode
WatchDog TimeOut Value
Chassis Opened Warning
ErP/EuP S5 Support
7.3.4.1 Serial Port 1 Configuration
Feature
Serial Port 1 Configuration
Serial Port
Device Setting
Change Settings
COM Mode Select
40
Options
NCT6106D
Second
Minute
0
Disabled
Enabled
Disabled
Enabled
Options
Disabled
Enabled
IO=3F8h; IRQ=4;
Auto
IO=3F8h; IRQ=4
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;
RS232
RS485 Half Duplex
RS422 Full Duplex
Description
Set Parameters of Serial Port 1.
Set Parameters of Serial Port 2.
Set Parameters of Serial Port 3.
Set Parameters of Serial Port 4.
Set Parameters of Serial Port 5.
WatchDog Count Mode Selection.
Fill WatchDog Timeout Value, 0 means disabled.
Select whether to enable Chassis Intrusion Detection.
Chassis Intrusion Detection is a utility that can tell
whether someone has opened the case (intruded into
the chassis).
Note: If chassis tamper occurs, you can only enter
setup to clear this error.
Enable/Disable ErP/EuP S5 Support.
Note: When MEBx is enable Activate Network Access,
this function can not set enable that will cause ME fail
on next boot.
Description
Enable or Disable Serial Port (COM).
Select optimal settings for Super IO Device.
Configure the COM Port Mode.
